| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_049T01_9000003380_22873cztM0_level2.evt | modeM0/AS1A07_049T01_9000003380_22873cztM0_level2_quad_clean.evt |
| Size (bytes) | 467,349,120 | 94,213,440 |
| Size | 445.7 MB | 89.8 MB |
| Events in quadrant A | 3,204,677 | 610,441 |
| Events in quadrant B | 3,321,778 | 616,511 |
| Events in quadrant C | 3,215,852 | 585,279 |
| Events in quadrant D | 3,955,325 | 573,223 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13826 | 2 |
| B | 0 | 13939 | 2 |
| C | 0 | 13942 | 2 |
| D | 0 | 16243 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 6 | 0 |
| D | 0 | 6 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6708 | 83 | 1.237329% |
| B | 6709 | 114 | 1.699210% |
| C | 6709 | 115 | 1.714115% |
| D | 6709 | 122 | 1.818453% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7328 | 6710 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7329 | 6711 | 6 | 6 | 0.08% | 0.09% |  |
| C | 7329 | 6711 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7329 | 6711 | 45 | 45 | 0.61% | 0.67% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 10804 | 59.91 | 829 | 813 | 166.8 |
| A | 6 | 16 | 7757 | 41.64 | 829 | 813 | 166.8 |
| A | 3 | 137 | 7164 | 38.08 | 829 | 813 | 166.8 |
| B | 0 | 189 | 77010 | 477.14 | 819 | 798 | 159.7 |
| B | 12 | 111 | 19090 | 114.52 | 819 | 798 | 159.7 |
| B | 11 | 111 | 16993 | 101.39 | 819 | 798 | 159.7 |
| C | 14 | 238 | 122364 | 657.74 | 782 | 787 | 184.8 |
| C | 10 | 22 | 39181 | 207.71 | 782 | 787 | 184.8 |
| C | 13 | 61 | 5534 | 25.68 | 782 | 787 | 184.8 |
| D | 7 | 238 | 318942 | 1622.16 | 803 | 780 | 196.1 |
| D | 12 | 233 | 138121 | 700.24 | 803 | 780 | 196.1 |
| D | 13 | 153 | 83962 | 424.11 | 803 | 780 | 196.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
