| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_049T01_9000003380_22878cztM0_level2.evt | modeM0/AS1A07_049T01_9000003380_22878cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,341,437,760 | 222,563,520 |
| Size | 1.2 GB | 212.3 MB |
| Events in quadrant A | 8,271,016 | 1,407,153 |
| Events in quadrant B | 8,500,614 | 1,424,894 |
| Events in quadrant C | 8,416,110 | 1,359,738 |
| Events in quadrant D | 14,217,874 | 1,303,800 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 36599 | 3 |
| B | 0 | 36907 | 3 |
| C | 0 | 36672 | 3 |
| D | 0 | 54910 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 366 | 0 |
| B | 0 | 366 | 0 |
| C | 0 | 366 | 0 |
| D | 0 | 366 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 18069 | 54 | 0.298854% |
| B | 18069 | 77 | 0.426144% |
| C | 18070 | 144 | 0.796901% |
| D | 18070 | 706 | 3.907028% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 20014 | 18072 | 0 | 0 | 0.00% | 0.00% |  |
| B | 20014 | 18072 | 2 | 2 | 0.01% | 0.01% |  |
| C | 20015 | 18073 | 1 | 1 | 0.00% | 0.01% |  |
| D | 20015 | 18073 | 617 | 617 | 3.08% | 3.41% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 29589 | 63.96 | 2143 | 2095 | 429.9 |
| A | 3 | 137 | 18954 | 39.22 | 2143 | 2095 | 429.9 |
| A | 0 | 226 | 18407 | 37.94 | 2143 | 2095 | 429.9 |
| B | 0 | 190 | 57282 | 135.92 | 2135 | 2081 | 406.1 |
| B | 12 | 111 | 51020 | 120.51 | 2135 | 2081 | 406.1 |
| B | 11 | 111 | 44888 | 105.41 | 2135 | 2081 | 406.1 |
| C | 14 | 238 | 321370 | 662.29 | 2054 | 2067 | 482.1 |
| C | 7 | 247 | 60857 | 121.94 | 2054 | 2067 | 482.1 |
| C | 10 | 22 | 37354 | 73.19 | 2054 | 2067 | 482.1 |
| D | 7 | 238 | 3931995 | 7810.81 | 2066 | 2006 | 503.1 |
| D | 1 | 52 | 832872 | 1651.34 | 2066 | 2006 | 503.1 |
| D | 12 | 233 | 651206 | 1290.28 | 2066 | 2006 | 503.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
