| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A08_009T01_9000003382_22894cztM0_level2.evt | modeM0/AS1A08_009T01_9000003382_22894cztM0_level2_quad_clean.evt |
| Size (bytes) | 462,320,640 | 108,397,440 |
| Size | 440.9 MB | 103.4 MB |
| Events in quadrant A | 3,292,065 | 706,839 |
| Events in quadrant B | 3,233,575 | 724,449 |
| Events in quadrant C | 3,268,295 | 696,677 |
| Events in quadrant D | 3,746,509 | 682,384 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14187 | 2 |
| B | 0 | 14090 | 2 |
| C | 0 | 14181 | 2 |
| D | 0 | 15802 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6782 | 13 | 0.191684% |
| B | 6782 | 15 | 0.221174% |
| C | 6782 | 68 | 1.002654% |
| D | 6782 | 130 | 1.916839% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7822 | 6783 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7822 | 6783 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7822 | 6783 | 6 | 6 | 0.08% | 0.09% |  |
| D | 7822 | 6783 | 85 | 85 | 1.09% | 1.25% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 252 | 173141 | 1063.78 | 808 | 791 | 162.0 |
| A | 13 | 254 | 11102 | 63.64 | 808 | 791 | 162.0 |
| A | 3 | 137 | 7177 | 39.42 | 808 | 791 | 162.0 |
| B | 4 | 173 | 31734 | 200.03 | 810 | 788 | 154.7 |
| B | 12 | 111 | 18636 | 115.37 | 810 | 788 | 154.7 |
| B | 11 | 111 | 16754 | 103.2 | 810 | 788 | 154.7 |
| C | 14 | 238 | 125028 | 679.35 | 786 | 791 | 182.9 |
| C | 0 | 239 | 49809 | 268.04 | 786 | 791 | 182.9 |
| C | 7 | 247 | 17673 | 92.31 | 786 | 791 | 182.9 |
| D | 12 | 233 | 206857 | 1079.62 | 784 | 762 | 190.9 |
| D | 13 | 153 | 133549 | 695.6 | 784 | 762 | 190.9 |
| D | 2 | 152 | 104254 | 542.14 | 784 | 762 | 190.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
