| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A08_009T01_9000003382_22916cztM0_level2.evt | modeM0/AS1A08_009T01_9000003382_22916cztM0_level2_quad_clean.evt |
| Size (bytes) | 445,043,520 | 96,073,920 |
| Size | 424.4 MB | 91.6 MB |
| Events in quadrant A | 3,039,480 | 624,938 |
| Events in quadrant B | 3,055,958 | 636,397 |
| Events in quadrant C | 2,998,618 | 606,744 |
| Events in quadrant D | 3,945,051 | 590,998 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13189 | 1 |
| B | 0 | 13278 | 1 |
| C | 0 | 13161 | 1 |
| D | 0 | 16049 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6454 | 96 | 1.487450% |
| B | 6455 | 88 | 1.363284% |
| C | 6455 | 91 | 1.409760% |
| D | 6455 | 166 | 2.571650% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7219 | 6455 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7220 | 6456 | 3 | 3 | 0.04% | 0.05% |  |
| C | 7220 | 6456 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7220 | 6456 | 92 | 92 | 1.27% | 1.43% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 252 | 73487 | 473.52 | 768 | 750 | 153.6 |
| A | 13 | 254 | 10434 | 63.04 | 768 | 750 | 153.6 |
| A | 0 | 226 | 7070 | 41.14 | 768 | 750 | 153.6 |
| B | 4 | 216 | 21129 | 140.92 | 760 | 740 | 144.7 |
| B | 0 | 229 | 19569 | 130.13 | 760 | 740 | 144.7 |
| B | 0 | 190 | 17985 | 119.19 | 760 | 740 | 144.7 |
| C | 14 | 238 | 118457 | 704.19 | 727 | 729 | 167.2 |
| C | 6 | 80 | 24504 | 142.21 | 727 | 729 | 167.2 |
| C | 7 | 247 | 14418 | 81.88 | 727 | 729 | 167.2 |
| D | 1 | 52 | 475172 | 2660.17 | 739 | 716 | 178.4 |
| D | 13 | 174 | 204547 | 1142.84 | 739 | 716 | 178.4 |
| D | 12 | 233 | 139574 | 778.55 | 739 | 716 | 178.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
