| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A08_009T01_9000003390_22939cztM0_level2.evt | modeM0/AS1A08_009T01_9000003390_22939cztM0_level2_quad_clean.evt |
| Size (bytes) | 517,152,960 | 102,686,400 |
| Size | 493.2 MB | 97.9 MB |
| Events in quadrant A | 3,019,699 | 677,719 |
| Events in quadrant B | 3,127,484 | 694,180 |
| Events in quadrant C | 3,138,979 | 670,090 |
| Events in quadrant D | 5,941,053 | 620,679 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13288 | 2 |
| B | 0 | 13627 | 2 |
| C | 0 | 13701 | 2 |
| D | 0 | 22188 | 7 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6408 | 12 | 0.187266% |
| B | 6408 | 26 | 0.405743% |
| C | 6408 | 64 | 0.998752% |
| D | 6407 | 816 | 12.736070% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7543 | 6409 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7543 | 6409 | 3 | 3 | 0.04% | 0.05% |  |
| C | 7543 | 6409 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7542 | 6408 | 634 | 634 | 8.41% | 9.89% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 10915 | 64.63 | 782 | 763 | 157.1 |
| A | 3 | 137 | 6651 | 37.48 | 782 | 763 | 157.1 |
| A | 0 | 226 | 6523 | 36.67 | 782 | 763 | 157.1 |
| B | 6 | 36 | 24151 | 157.62 | 786 | 766 | 148.4 |
| B | 12 | 111 | 17668 | 113.92 | 786 | 766 | 148.4 |
| B | 11 | 111 | 15384 | 98.53 | 786 | 766 | 148.4 |
| C | 14 | 238 | 121436 | 687.6 | 760 | 767 | 175.5 |
| C | 0 | 239 | 41211 | 230.46 | 760 | 767 | 175.5 |
| C | 7 | 247 | 10483 | 55.36 | 760 | 767 | 175.5 |
| D | 1 | 239 | 1452162 | 8279.13 | 727 | 708 | 175.3 |
| D | 1 | 52 | 829490 | 4727.4 | 727 | 708 | 175.3 |
| D | 7 | 238 | 377952 | 2151.81 | 727 | 708 | 175.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
