| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A08_009T01_9000003390_22960cztM0_level2.evt | modeM0/AS1A08_009T01_9000003390_22960cztM0_level2_quad_clean.evt |
| Size (bytes) | 540,336,960 | 101,191,680 |
| Size | 515.3 MB | 96.5 MB |
| Events in quadrant A | 3,158,219 | 662,617 |
| Events in quadrant B | 3,372,935 | 676,364 |
| Events in quadrant C | 3,344,413 | 645,524 |
| Events in quadrant D | 6,018,862 | 597,815 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 5 | 0 |
| C | 0 | 5 | 0 |
| D | 0 | 5 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14104 | 1 |
| B | 0 | 14612 | 1 |
| C | 0 | 14306 | 1 |
| D | 0 | 22675 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6920 | 112 | 1.618497% |
| B | 6920 | 138 | 1.994220% |
| C | 6920 | 110 | 1.589595% |
| D | 6920 | 770 | 11.127168% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7405 | 6921 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7405 | 6921 | 16 | 16 | 0.22% | 0.23% |  |
| C | 7405 | 6921 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7405 | 6921 | 523 | 523 | 7.06% | 7.56% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 11353 | 64.0 | 818 | 801 | 164.9 |
| A | 3 | 137 | 7088 | 38.13 | 818 | 801 | 164.9 |
| A | 0 | 226 | 7047 | 37.88 | 818 | 801 | 164.9 |
| B | 0 | 190 | 124893 | 806.31 | 811 | 790 | 153.9 |
| B | 4 | 216 | 39577 | 252.0 | 811 | 790 | 153.9 |
| B | 12 | 111 | 18811 | 117.08 | 811 | 790 | 153.9 |
| C | 0 | 10 | 179240 | 981.53 | 776 | 777 | 181.8 |
| C | 14 | 238 | 125542 | 686.19 | 776 | 777 | 181.8 |
| C | 0 | 239 | 13489 | 69.91 | 776 | 777 | 181.8 |
| D | 1 | 52 | 2467124 | 13477.58 | 755 | 731 | 183.0 |
| D | 13 | 153 | 526696 | 2874.13 | 755 | 731 | 183.0 |
| D | 13 | 172 | 83663 | 453.18 | 755 | 731 | 183.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
