| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_062T01_9000003392_22971cztM0_level2.evt | modeM0/AS1A07_062T01_9000003392_22971cztM0_level2_quad_clean.evt |
| Size (bytes) | 461,914,560 | 83,554,560 |
| Size | 440.5 MB | 79.7 MB |
| Events in quadrant A | 3,250,195 | 534,815 |
| Events in quadrant B | 3,375,861 | 550,825 |
| Events in quadrant C | 3,435,794 | 506,166 |
| Events in quadrant D | 3,495,732 | 495,052 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22 | 0 |
| B | 0 | 23 | 0 |
| C | 0 | 23 | 0 |
| D | 0 | 23 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13471 | 2 |
| B | 0 | 13865 | 3 |
| C | 0 | 14008 | 2 |
| D | 0 | 14546 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6357 | 33 | 0.519113% |
| B | 6356 | 55 | 0.865324% |
| C | 6356 | 133 | 2.092511% |
| D | 6356 | 82 | 1.290120% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7697 | 6358 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7696 | 6357 | 5 | 5 | 0.06% | 0.08% |  |
| C | 7696 | 6357 | 19 | 19 | 0.25% | 0.30% |  |
| D | 7696 | 6357 | 36 | 36 | 0.47% | 0.57% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 16 | 26735 | 155.93 | 835 | 819 | 166.2 |
| A | 13 | 254 | 11088 | 61.79 | 835 | 819 | 166.2 |
| A | 0 | 226 | 7261 | 38.76 | 835 | 819 | 166.2 |
| B | 0 | 183 | 29993 | 185.77 | 842 | 824 | 157.0 |
| B | 0 | 190 | 22794 | 139.92 | 842 | 824 | 157.0 |
| B | 12 | 111 | 18321 | 111.44 | 842 | 824 | 157.0 |
| C | 14 | 238 | 129704 | 700.61 | 801 | 809 | 184.0 |
| C | 0 | 10 | 129333 | 698.59 | 801 | 809 | 184.0 |
| C | 0 | 239 | 45182 | 241.19 | 801 | 809 | 184.0 |
| D | 13 | 153 | 195510 | 987.93 | 806 | 784 | 197.1 |
| D | 1 | 52 | 139426 | 703.39 | 806 | 784 | 197.1 |
| D | 7 | 38 | 54014 | 270.06 | 806 | 784 | 197.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
