| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A08_004T03_9000003400_22991cztM0_level2.evt | modeM0/AS1A08_004T03_9000003400_22991cztM0_level2_quad_clean.evt |
| Size (bytes) | 512,591,040 | 97,669,440 |
| Size | 488.8 MB | 93.1 MB |
| Events in quadrant A | 3,318,330 | 627,564 |
| Events in quadrant B | 3,421,796 | 637,069 |
| Events in quadrant C | 3,370,136 | 611,626 |
| Events in quadrant D | 4,935,717 | 591,565 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14464 | 2 |
| B | 0 | 14616 | 2 |
| C | 0 | 14555 | 2 |
| D | 0 | 19289 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 144 | 0 |
| B | 0 | 144 | 0 |
| C | 0 | 144 | 0 |
| D | 0 | 144 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7031 | 140 | 1.991182% |
| B | 7032 | 158 | 2.246871% |
| C | 7032 | 142 | 2.019340% |
| D | 7032 | 179 | 2.545506% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7276 | 7033 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7277 | 7034 | 1 | 1 | 0.01% | 0.01% |  |
| C | 7277 | 7034 | 1 | 1 | 0.01% | 0.01% |  |
| D | 7277 | 7034 | 68 | 68 | 0.93% | 0.97% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 12208 | 65.34 | 858 | 838 | 174.0 |
| A | 14 | 237 | 8287 | 42.81 | 858 | 838 | 174.0 |
| A | 3 | 137 | 7776 | 39.87 | 858 | 838 | 174.0 |
| B | 0 | 190 | 45744 | 270.43 | 851 | 830 | 166.1 |
| B | 0 | 189 | 27069 | 157.99 | 851 | 830 | 166.1 |
| B | 12 | 111 | 20133 | 116.23 | 851 | 830 | 166.1 |
| C | 14 | 238 | 128532 | 656.84 | 821 | 826 | 194.4 |
| C | 0 | 207 | 30311 | 151.65 | 821 | 826 | 194.4 |
| C | 7 | 247 | 9317 | 43.67 | 821 | 826 | 194.4 |
| D | 1 | 52 | 1118172 | 5418.88 | 833 | 806 | 206.2 |
| D | 1 | 239 | 278107 | 1344.82 | 833 | 806 | 206.2 |
| D | 13 | 153 | 118762 | 572.05 | 833 | 806 | 206.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
