| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A08_004T03_9000003400_23008cztM0_level2.evt | modeM0/AS1A08_004T03_9000003400_23008cztM0_level2_quad_clean.evt |
| Size (bytes) | 676,753,920 | 98,447,040 |
| Size | 645.4 MB | 93.9 MB |
| Events in quadrant A | 4,364,741 | 600,107 |
| Events in quadrant B | 4,486,565 | 604,669 |
| Events in quadrant C | 5,119,365 | 572,548 |
| Events in quadrant D | 5,899,247 | 563,408 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20151 | 879 |
| B | 0 | 20327 | 984 |
| C | 0 | 23022 | 1485 |
| D | 0 | 25098 | 1476 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 198 | 10 |
| B | 0 | 197 | 9 |
| C | 0 | 195 | 5 |
| D | 0 | 199 | 11 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 2 |
| B | 0 | 14 | 2 |
| C | 0 | 12 | 0 |
| D | 0 | 13 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 9238 | 87 | 0.941762% |
| B | 9238 | 119 | 1.288158% |
| C | 9229 | 394 | 4.269152% |
| D | 9225 | 163 | 1.766938% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 13189 | 9267 | 0 | 0 | 0.00% | 0.00% |  |
| B | 13179 | 9266 | 10 | 10 | 0.08% | 0.11% |  |
| C | 13183 | 9249 | 156 | 156 | 1.18% | 1.69% |  |
| D | 13182 | 9244 | 79 | 79 | 0.60% | 0.85% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 11 | 47 | 184297 | 835.23 | 1085 | 1058 | 219.4 |
| A | 13 | 254 | 12463 | 51.98 | 1085 | 1058 | 219.4 |
| A | 3 | 137 | 9656 | 39.19 | 1085 | 1058 | 219.4 |
| B | 5 | 172 | 82802 | 391.45 | 1084 | 1057 | 208.8 |
| B | 4 | 216 | 45769 | 214.11 | 1084 | 1057 | 208.8 |
| B | 0 | 189 | 36646 | 170.42 | 1084 | 1057 | 208.8 |
| C | 9 | 15 | 898678 | 3650.14 | 1038 | 1043 | 245.9 |
| C | 14 | 238 | 163597 | 661.01 | 1038 | 1043 | 245.9 |
| C | 10 | 9 | 8661 | 30.98 | 1038 | 1043 | 245.9 |
| D | 12 | 227 | 929704 | 3585.14 | 1056 | 1026 | 259.0 |
| D | 1 | 52 | 598785 | 2307.63 | 1056 | 1026 | 259.0 |
| D | 13 | 153 | 142436 | 545.91 | 1056 | 1026 | 259.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
