| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_049T01_9000003408_23090cztM0_level2.evt | modeM0/AS1A07_049T01_9000003408_23090cztM0_level2_quad_clean.evt |
| Size (bytes) | 761,328,000 | 75,415,680 |
| Size | 726.1 MB | 71.9 MB |
| Events in quadrant A | 11,281,083 | 321,221 |
| Events in quadrant B | 3,452,556 | 507,093 |
| Events in quadrant C | 3,777,019 | 487,272 |
| Events in quadrant D | 4,071,935 | 478,936 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 38141 | 2 |
| B | 0 | 14591 | 2 |
| C | 0 | 15445 | 2 |
| D | 0 | 16746 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 144 | 0 |
| B | 0 | 144 | 0 |
| C | 0 | 144 | 0 |
| D | 0 | 144 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7002 | 3265 | 46.629534% |
| B | 7002 | 145 | 2.070837% |
| C | 7002 | 210 | 2.999143% |
| D | 7001 | 251 | 3.585202% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7657 | 7002 | 2718 | 2718 | 35.50% | 38.82% |  |
| B | 7657 | 7003 | 2 | 2 | 0.03% | 0.03% |  |
| C | 7657 | 7003 | 25 | 25 | 0.33% | 0.36% |  |
| D | 7656 | 7002 | 118 | 118 | 1.54% | 1.69% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 16 | 8823079 | 69473.64 | 635 | 622 | 127.0 |
| A | 5 | 98 | 10825 | 80.34 | 635 | 622 | 127.0 |
| A | 13 | 254 | 7775 | 56.33 | 635 | 622 | 127.0 |
| B | 12 | 111 | 20572 | 117.88 | 869 | 850 | 167.3 |
| B | 11 | 111 | 18569 | 105.91 | 869 | 850 | 167.3 |
| B | 14 | 111 | 16454 | 93.27 | 869 | 850 | 167.3 |
| C | 0 | 10 | 177859 | 906.33 | 837 | 843 | 195.3 |
| C | 14 | 238 | 131589 | 669.42 | 837 | 843 | 195.3 |
| C | 0 | 207 | 121782 | 619.21 | 837 | 843 | 195.3 |
| D | 13 | 172 | 545852 | 2674.99 | 840 | 819 | 203.8 |
| D | 12 | 227 | 215592 | 1054.09 | 840 | 819 | 203.8 |
| D | 1 | 52 | 121689 | 593.22 | 840 | 819 | 203.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
