| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A08_003T05_9000003426_23179cztM0_level2.evt | modeM0/AS1A08_003T05_9000003426_23179cztM0_level2_quad_clean.evt |
| Size (bytes) | 758,154,240 | 116,225,280 |
| Size | 723.0 MB | 110.8 MB |
| Events in quadrant A | 8,005,467 | 691,678 |
| Events in quadrant B | 4,319,836 | 776,664 |
| Events in quadrant C | 4,478,824 | 739,912 |
| Events in quadrant D | 5,585,879 | 725,312 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 29592 | 3 |
| B | 0 | 18403 | 3 |
| C | 0 | 18507 | 3 |
| D | 0 | 22389 | 3 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 178 | 0 |
| B | 0 | 178 | 0 |
| C | 0 | 178 | 0 |
| D | 0 | 178 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8425 | 1707 | 20.261128% |
| B | 8426 | 294 | 3.489200% |
| C | 8426 | 291 | 3.453596% |
| D | 8426 | 372 | 4.414906% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8890 | 8428 | 1227 | 1227 | 13.80% | 14.56% |  |
| B | 8891 | 8430 | 32 | 32 | 0.36% | 0.38% |  |
| C | 8891 | 8430 | 10 | 10 | 0.11% | 0.12% |  |
| D | 8891 | 8430 | 144 | 144 | 1.62% | 1.71% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 16 | 4225126 | 21055.45 | 980 | 959 | 200.6 |
| A | 13 | 254 | 10851 | 49.3 | 980 | 959 | 200.6 |
| A | 3 | 137 | 8986 | 40.01 | 980 | 959 | 200.6 |
| B | 0 | 245 | 128990 | 615.65 | 1049 | 1017 | 207.9 |
| B | 0 | 190 | 36530 | 170.85 | 1049 | 1017 | 207.9 |
| B | 0 | 244 | 33280 | 155.21 | 1049 | 1017 | 207.9 |
| C | 0 | 10 | 368435 | 1539.3 | 1002 | 1008 | 238.7 |
| C | 14 | 238 | 158164 | 658.39 | 1002 | 1008 | 238.7 |
| C | 7 | 247 | 23918 | 95.98 | 1002 | 1008 | 238.7 |
| D | 7 | 238 | 568752 | 2240.77 | 1015 | 984 | 253.4 |
| D | 13 | 153 | 371939 | 1464.02 | 1015 | 984 | 253.4 |
| D | 12 | 218 | 364280 | 1433.8 | 1015 | 984 | 253.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
