| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A08_008T02_9000003430_23220cztM0_level2.evt | modeM0/AS1A08_008T02_9000003430_23220cztM0_level2_quad_clean.evt |
| Size (bytes) | 166,455,360 | 34,032,960 |
| Size | 158.7 MB | 32.5 MB |
| Events in quadrant A | 811,135 | 242,154 |
| Events in quadrant B | 845,542 | 248,025 |
| Events in quadrant C | 930,488 | 227,303 |
| Events in quadrant D | 2,330,005 | 181,769 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3652 | 1 |
| B | 0 | 3681 | 1 |
| C | 0 | 3941 | 1 |
| D | 0 | 8126 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 36 | 0 |
| B | 0 | 36 | 0 |
| C | 0 | 36 | 0 |
| D | 0 | 36 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 1785 | 6 | 0.336134% |
| B | 1785 | 13 | 0.728291% |
| C | 1785 | 56 | 3.137255% |
| D | 1785 | 568 | 31.820728% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 1785 | 1785 | 0 | 0 | 0.00% | 0.00% |  |
| B | 1785 | 1785 | 0 | 0 | 0.00% | 0.00% |  |
| C | 1785 | 1785 | 25 | 25 | 1.40% | 1.40% |  |
| D | 1785 | 1785 | 546 | 546 | 30.59% | 30.59% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 3059 | 64.68 | 210 | 206 | 44.1 |
| A | 3 | 137 | 1802 | 36.18 | 210 | 206 | 44.1 |
| A | 0 | 226 | 1795 | 36.02 | 210 | 206 | 44.1 |
| B | 0 | 190 | 7148 | 165.08 | 213 | 208 | 42.0 |
| B | 12 | 111 | 4644 | 105.52 | 213 | 208 | 42.0 |
| B | 3 | 209 | 4085 | 92.22 | 213 | 208 | 42.0 |
| C | 0 | 10 | 134583 | 2896.7 | 193 | 194 | 46.4 |
| C | 14 | 238 | 31604 | 677.03 | 193 | 194 | 46.4 |
| C | 0 | 239 | 5357 | 111.29 | 193 | 194 | 46.4 |
| D | 1 | 52 | 1371284 | 32024.51 | 167 | 162 | 42.8 |
| D | 7 | 238 | 99009 | 2308.71 | 167 | 162 | 42.8 |
| D | 12 | 233 | 80336 | 1872.58 | 167 | 162 | 42.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
