| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A08_009T01_9000003434_23234cztM0_level2.evt | modeM0/AS1A08_009T01_9000003434_23234cztM0_level2_quad_clean.evt |
| Size (bytes) | 492,459,840 | 118,082,880 |
| Size | 469.6 MB | 112.6 MB |
| Events in quadrant A | 3,139,131 | 789,975 |
| Events in quadrant B | 3,205,523 | 806,660 |
| Events in quadrant C | 3,334,880 | 781,426 |
| Events in quadrant D | 4,790,797 | 742,563 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13606 | 2 |
| B | 0 | 13739 | 2 |
| C | 0 | 14042 | 3 |
| D | 0 | 18879 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6531 | 60 | 0.918695% |
| B | 6531 | 78 | 1.194304% |
| C | 6530 | 169 | 2.588055% |
| D | 6531 | 428 | 6.553361% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7532 | 6533 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7532 | 6533 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7531 | 6532 | 12 | 12 | 0.16% | 0.18% |  |
| D | 7532 | 6533 | 295 | 295 | 3.92% | 4.52% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 252 | 27885 | 168.71 | 804 | 789 | 160.6 |
| A | 13 | 254 | 11029 | 63.76 | 804 | 789 | 160.6 |
| A | 3 | 137 | 6960 | 38.42 | 804 | 789 | 160.6 |
| B | 0 | 190 | 32615 | 211.02 | 808 | 787 | 150.8 |
| B | 12 | 111 | 17763 | 112.55 | 808 | 787 | 150.8 |
| B | 11 | 111 | 15578 | 98.06 | 808 | 787 | 150.8 |
| C | 14 | 238 | 125220 | 688.12 | 785 | 791 | 180.8 |
| C | 0 | 10 | 120634 | 662.76 | 785 | 791 | 180.8 |
| C | 7 | 247 | 19410 | 102.97 | 785 | 791 | 180.8 |
| D | 1 | 52 | 406506 | 2151.32 | 780 | 758 | 188.6 |
| D | 2 | 152 | 388620 | 2056.49 | 780 | 758 | 188.6 |
| D | 12 | 233 | 328614 | 1738.33 | 780 | 758 | 188.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
