| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A08_004T02_9000003436_23241cztM0_level2.evt | modeM0/AS1A08_004T02_9000003436_23241cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,127,125,440 | 304,027,200 |
| Size | 1.0 GB | 289.9 MB |
| Events in quadrant A | 7,513,138 | 2,053,316 |
| Events in quadrant B | 7,739,261 | 2,087,073 |
| Events in quadrant C | 8,818,468 | 1,986,064 |
| Events in quadrant D | 8,951,712 | 1,948,713 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 334 | 0 |
| B | 0 | 334 | 0 |
| C | 0 | 334 | 0 |
| D | 0 | 334 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 33390 | 3 |
| B | 0 | 33786 | 3 |
| C | 0 | 37115 | 3 |
| D | 0 | 37602 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24 | 0 |
| B | 0 | 24 | 0 |
| C | 0 | 24 | 0 |
| D | 0 | 24 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 16447 | 148 | 0.899860% |
| B | 16448 | 206 | 1.252432% |
| C | 16448 | 378 | 2.298152% |
| D | 16448 | 369 | 2.243434% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 18782 | 16448 | 0 | 0 | 0.00% | 0.00% |  |
| B | 18783 | 16448 | 19 | 19 | 0.10% | 0.12% |  |
| C | 18783 | 16448 | 48 | 48 | 0.26% | 0.29% |  |
| D | 18783 | 16449 | 203 | 203 | 1.08% | 1.23% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 16 | 60203 | 150.45 | 1929 | 1887 | 387.6 |
| A | 13 | 254 | 25019 | 59.68 | 1929 | 1887 | 387.6 |
| A | 3 | 137 | 16942 | 38.84 | 1929 | 1887 | 387.6 |
| B | 12 | 17 | 52425 | 138.25 | 1925 | 1873 | 365.6 |
| B | 12 | 111 | 44448 | 116.44 | 1925 | 1873 | 365.6 |
| B | 11 | 111 | 39229 | 102.16 | 1925 | 1873 | 365.6 |
| C | 8 | 208 | 1029019 | 2420.7 | 1842 | 1855 | 424.3 |
| C | 14 | 238 | 293591 | 687.53 | 1842 | 1855 | 424.3 |
| C | 0 | 10 | 116790 | 270.87 | 1842 | 1855 | 424.3 |
| D | 12 | 233 | 595932 | 1318.21 | 1866 | 1812 | 450.7 |
| D | 1 | 52 | 443052 | 979.0 | 1866 | 1812 | 450.7 |
| D | 2 | 152 | 333971 | 736.98 | 1866 | 1812 | 450.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
