| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C05_005T01_9000003440_23278cztM0_level2.evt | modeM0/AS1C05_005T01_9000003440_23278cztM0_level2_quad_clean.evt |
| Size (bytes) | 521,832,960 | 112,996,800 |
| Size | 497.7 MB | 107.8 MB |
| Events in quadrant A | 3,457,782 | 740,195 |
| Events in quadrant B | 3,856,961 | 751,878 |
| Events in quadrant C | 3,613,773 | 724,056 |
| Events in quadrant D | 4,385,100 | 703,371 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 19 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15081 | 2 |
| B | 0 | 15840 | 2 |
| C | 0 | 15325 | 2 |
| D | 0 | 17876 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7221 | 84 | 1.163274% |
| B | 7222 | 126 | 1.744669% |
| C | 7222 | 162 | 2.243146% |
| D | 7222 | 238 | 3.295486% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9161 | 7223 | 0 | 0 | 0.00% | 0.00% |  |
| B | 9162 | 7223 | 0 | 0 | 0.00% | 0.00% |  |
| C | 9162 | 7223 | 0 | 0 | 0.00% | 0.00% |  |
| D | 9162 | 7224 | 94 | 94 | 1.03% | 1.30% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 12520 | 64.62 | 896 | 876 | 180.2 |
| A | 3 | 137 | 8021 | 39.65 | 896 | 876 | 180.2 |
| A | 0 | 226 | 7677 | 37.74 | 896 | 876 | 180.2 |
| B | 4 | 206 | 336146 | 1975.49 | 895 | 871 | 169.7 |
| B | 12 | 111 | 20170 | 113.71 | 895 | 871 | 169.7 |
| B | 11 | 111 | 18035 | 101.13 | 895 | 871 | 169.7 |
| C | 14 | 238 | 136399 | 671.98 | 870 | 876 | 201.7 |
| C | 10 | 9 | 48643 | 236.85 | 870 | 876 | 201.7 |
| C | 8 | 208 | 16052 | 75.25 | 870 | 876 | 201.7 |
| D | 7 | 238 | 508478 | 2409.58 | 874 | 850 | 210.7 |
| D | 1 | 239 | 350475 | 1659.58 | 874 | 850 | 210.7 |
| D | 12 | 233 | 128003 | 603.56 | 874 | 850 | 210.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
