| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_135T02_9000003450_23336cztM0_level2.evt | modeM0/AS1A07_135T02_9000003450_23336cztM0_level2_quad_clean.evt |
| Size (bytes) | 895,495,680 | 67,893,120 |
| Size | 854.0 MB | 64.7 MB |
| Events in quadrant A | 3,383,980 | 427,017 |
| Events in quadrant B | 3,469,791 | 431,404 |
| Events in quadrant C | 3,502,646 | 424,138 |
| Events in quadrant D | 16,301,342 | 295,939 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7 | 0 |
| B | 0 | 7 | 0 |
| C | 0 | 7 | 0 |
| D | 0 | 7 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14175 | 1 |
| B | 0 | 14346 | 1 |
| C | 0 | 14421 | 1 |
| D | 0 | 53024 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6830 | 79 | 1.156662% |
| B | 6830 | 99 | 1.449488% |
| C | 6830 | 147 | 2.152269% |
| D | 6830 | 6460 | 94.582723% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7550 | 6831 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7550 | 6830 | 1 | 1 | 0.01% | 0.01% |  |
| C | 7550 | 6831 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7549 | 6829 | 6416 | 6416 | 84.99% | 93.95% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 10171 | 52.55 | 878 | 860 | 177.2 |
| A | 3 | 137 | 7800 | 39.17 | 878 | 860 | 177.2 |
| A | 0 | 226 | 7421 | 37.03 | 878 | 860 | 177.2 |
| B | 12 | 111 | 20528 | 117.71 | 870 | 850 | 167.2 |
| B | 0 | 190 | 19224 | 109.91 | 870 | 850 | 167.2 |
| B | 11 | 111 | 17999 | 102.59 | 870 | 850 | 167.2 |
| C | 14 | 238 | 134332 | 667.47 | 850 | 856 | 200.0 |
| C | 7 | 247 | 45732 | 224.41 | 850 | 856 | 200.0 |
| C | 3 | 233 | 5834 | 24.89 | 850 | 856 | 200.0 |
| D | 7 | 223 | 13727507 | 94609.03 | 597 | 580 | 145.1 |
| D | 1 | 52 | 156442 | 1074.24 | 597 | 580 | 145.1 |
| D | 12 | 233 | 63255 | 431.97 | 597 | 580 | 145.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
