| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_138T09_9000003458_23367cztM0_level2.evt | modeM0/AS1A07_138T09_9000003458_23367cztM0_level2_quad_clean.evt |
| Size (bytes) | 459,898,560 | 75,870,720 |
| Size | 438.6 MB | 72.4 MB |
| Events in quadrant A | 2,551,455 | 485,685 |
| Events in quadrant B | 2,648,853 | 489,979 |
| Events in quadrant C | 5,022,846 | 467,098 |
| Events in quadrant D | 3,332,636 | 470,876 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 112 | 0 |
| B | 0 | 112 | 0 |
| C | 0 | 112 | 0 |
| D | 0 | 112 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11255 | 2 |
| B | 0 | 11466 | 1 |
| C | 0 | 18904 | 1 |
| D | 0 | 13690 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5481 | 29 | 0.529101% |
| B | 5481 | 53 | 0.966977% |
| C | 5481 | 485 | 8.848750% |
| D | 5481 | 142 | 2.590768% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5786 | 5482 | 0 | 0 | 0.00% | 0.00% |  |
| B | 5786 | 5482 | 6 | 6 | 0.10% | 0.11% |  |
| C | 5786 | 5482 | 114 | 114 | 1.97% | 2.08% |  |
| D | 5786 | 5482 | 82 | 82 | 1.42% | 1.50% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 7761 | 52.93 | 661 | 646 | 134.4 |
| A | 3 | 137 | 5952 | 39.47 | 661 | 646 | 134.4 |
| A | 0 | 226 | 5710 | 37.67 | 661 | 646 | 134.4 |
| B | 6 | 36 | 19781 | 150.3 | 655 | 638 | 127.4 |
| B | 0 | 190 | 16496 | 124.51 | 655 | 638 | 127.4 |
| B | 12 | 111 | 15425 | 116.1 | 655 | 638 | 127.4 |
| C | 0 | 239 | 2454892 | 16890.3 | 622 | 625 | 145.3 |
| C | 14 | 238 | 96617 | 660.62 | 622 | 625 | 145.3 |
| C | 7 | 247 | 28765 | 193.66 | 622 | 625 | 145.3 |
| D | 7 | 238 | 510754 | 3274.06 | 640 | 622 | 155.8 |
| D | 13 | 104 | 168343 | 1076.44 | 640 | 622 | 155.8 |
| D | 1 | 52 | 137150 | 876.25 | 640 | 622 | 155.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
