| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_138T09_9000003458_23372cztM0_level2.evt | modeM0/AS1A07_138T09_9000003458_23372cztM0_level2_quad_clean.evt |
| Size (bytes) | 427,648,320 | 98,737,920 |
| Size | 407.8 MB | 94.2 MB |
| Events in quadrant A | 2,946,743 | 645,555 |
| Events in quadrant B | 3,209,855 | 660,344 |
| Events in quadrant C | 3,211,036 | 629,175 |
| Events in quadrant D | 3,153,900 | 614,157 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 129 | 1 |
| C | 0 | 128 | 2 |
| D | 0 | 130 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13040 | 94 |
| B | 0 | 13693 | 100 |
| C | 0 | 13780 | 210 |
| D | 0 | 13813 | 100 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6322 | 26 | 0.411262% |
| B | 6325 | 51 | 0.806324% |
| C | 6322 | 79 | 1.249605% |
| D | 6326 | 36 | 0.569080% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7731 | 6326 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7730 | 6328 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7730 | 6328 | 2 | 2 | 0.03% | 0.03% |  |
| D | 7730 | 6330 | 6 | 6 | 0.08% | 0.09% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 9573 | 57.12 | 764 | 749 | 154.5 |
| A | 3 | 137 | 6632 | 38.08 | 764 | 749 | 154.5 |
| A | 0 | 226 | 6515 | 37.33 | 764 | 749 | 154.5 |
| B | 0 | 189 | 154945 | 1044.89 | 767 | 745 | 147.6 |
| B | 0 | 229 | 44463 | 296.24 | 767 | 745 | 147.6 |
| B | 12 | 111 | 17631 | 114.42 | 767 | 745 | 147.6 |
| C | 0 | 239 | 156719 | 921.64 | 729 | 733 | 169.2 |
| C | 14 | 238 | 117360 | 689.09 | 729 | 733 | 169.2 |
| C | 7 | 247 | 46772 | 272.02 | 729 | 733 | 169.2 |
| D | 1 | 52 | 133798 | 744.73 | 737 | 715 | 178.7 |
| D | 13 | 104 | 54459 | 300.75 | 737 | 715 | 178.7 |
| D | 7 | 238 | 46455 | 255.96 | 737 | 715 | 178.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
