| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_138T09_9000003458_23382cztM0_level2.evt | modeM0/AS1A07_138T09_9000003458_23382cztM0_level2_quad_clean.evt |
| Size (bytes) | 511,562,880 | 88,634,880 |
| Size | 487.9 MB | 84.5 MB |
| Events in quadrant A | 3,455,095 | 550,047 |
| Events in quadrant B | 3,533,129 | 553,488 |
| Events in quadrant C | 3,910,381 | 537,277 |
| Events in quadrant D | 4,096,875 | 533,387 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15157 | 1 |
| B | 0 | 15295 | 1 |
| C | 0 | 16309 | 1 |
| D | 0 | 17175 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7325 | 40 | 0.546075% |
| B | 7326 | 63 | 0.859951% |
| C | 7326 | 147 | 2.006552% |
| D | 7326 | 105 | 1.433251% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7690 | 7326 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7691 | 7327 | 1 | 1 | 0.01% | 0.01% |  |
| C | 7691 | 7326 | 16 | 16 | 0.21% | 0.22% |  |
| D | 7691 | 7327 | 49 | 49 | 0.64% | 0.67% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 72373 | 403.01 | 877 | 860 | 177.4 |
| A | 13 | 254 | 11142 | 57.94 | 877 | 860 | 177.4 |
| A | 3 | 137 | 7894 | 39.64 | 877 | 860 | 177.4 |
| B | 0 | 189 | 56778 | 334.36 | 869 | 845 | 167.3 |
| B | 0 | 190 | 32330 | 188.21 | 869 | 845 | 167.3 |
| B | 0 | 229 | 20452 | 117.21 | 869 | 845 | 167.3 |
| C | 0 | 239 | 297405 | 1500.48 | 841 | 844 | 197.6 |
| C | 10 | 9 | 184841 | 930.95 | 841 | 844 | 197.6 |
| C | 14 | 238 | 134898 | 678.26 | 841 | 844 | 197.6 |
| D | 1 | 52 | 583716 | 2769.13 | 857 | 831 | 210.5 |
| D | 7 | 238 | 134137 | 633.3 | 857 | 831 | 210.5 |
| D | 13 | 104 | 52235 | 244.21 | 857 | 831 | 210.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
