| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_100T02_9000003470_23448cztM0_level2.evt | modeM0/AS1A07_100T02_9000003470_23448cztM0_level2_quad_clean.evt |
| Size (bytes) | 646,447,680 | 100,514,880 |
| Size | 616.5 MB | 95.9 MB |
| Events in quadrant A | 3,021,802 | 702,893 |
| Events in quadrant B | 3,158,066 | 716,925 |
| Events in quadrant C | 3,148,433 | 688,978 |
| Events in quadrant D | 9,858,023 | 530,244 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12349 | 1 |
| B | 0 | 12766 | 2 |
| C | 0 | 12839 | 1 |
| D | 0 | 33338 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 118 | 0 |
| B | 0 | 118 | 0 |
| C | 0 | 118 | 0 |
| D | 0 | 118 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5784 | 17 | 0.293914% |
| B | 5783 | 38 | 0.657098% |
| C | 5783 | 83 | 1.435241% |
| D | 5783 | 2428 | 41.985129% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7139 | 5785 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7138 | 5784 | 8 | 8 | 0.11% | 0.14% |  |
| C | 7138 | 5784 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7137 | 5783 | 2350 | 2350 | 32.93% | 40.64% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 8966 | 53.06 | 784 | 770 | 154.5 |
| A | 0 | 226 | 6798 | 39.02 | 784 | 770 | 154.5 |
| A | 3 | 137 | 5944 | 33.5 | 784 | 770 | 154.5 |
| B | 0 | 229 | 52056 | 363.51 | 777 | 760 | 141.1 |
| B | 0 | 183 | 23647 | 162.19 | 777 | 760 | 141.1 |
| B | 0 | 190 | 19670 | 134.01 | 777 | 760 | 141.1 |
| C | 14 | 238 | 124509 | 705.76 | 769 | 777 | 175.3 |
| C | 7 | 247 | 17005 | 92.56 | 769 | 777 | 175.3 |
| C | 13 | 61 | 5225 | 25.37 | 769 | 777 | 175.3 |
| D | 1 | 52 | 4981241 | 31303.08 | 663 | 647 | 159.1 |
| D | 7 | 238 | 2138932 | 13439.14 | 663 | 647 | 159.1 |
| D | 5 | 172 | 162397 | 1016.6 | 663 | 647 | 159.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
