| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_100T02_9000003470_23465cztM0_level2.evt | modeM0/AS1A07_100T02_9000003470_23465cztM0_level2_quad_clean.evt |
| Size (bytes) | 483,629,760 | 96,658,560 |
| Size | 461.2 MB | 92.2 MB |
| Events in quadrant A | 3,103,856 | 638,489 |
| Events in quadrant B | 3,188,975 | 646,728 |
| Events in quadrant C | 3,194,546 | 619,049 |
| Events in quadrant D | 4,742,919 | 594,392 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12758 | 2 |
| B | 0 | 12960 | 1 |
| C | 0 | 13062 | 1 |
| D | 0 | 18137 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6140 | 67 | 1.091205% |
| B | 6140 | 59 | 0.960912% |
| C | 6141 | 102 | 1.660967% |
| D | 6141 | 279 | 4.543234% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7325 | 6140 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7325 | 6140 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7326 | 6142 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7326 | 6141 | 200 | 200 | 2.73% | 3.26% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 10858 | 63.02 | 803 | 787 | 159.8 |
| A | 0 | 226 | 7125 | 39.66 | 803 | 787 | 159.8 |
| A | 6 | 16 | 6858 | 37.99 | 803 | 787 | 159.8 |
| B | 0 | 228 | 20906 | 139.14 | 791 | 775 | 144.7 |
| B | 12 | 111 | 16634 | 109.61 | 791 | 775 | 144.7 |
| B | 7 | 219 | 16563 | 109.12 | 791 | 775 | 144.7 |
| C | 14 | 238 | 123510 | 697.11 | 770 | 777 | 176.1 |
| C | 1 | 16 | 25461 | 140.2 | 770 | 777 | 176.1 |
| C | 0 | 207 | 19702 | 107.49 | 770 | 777 | 176.1 |
| D | 1 | 52 | 922995 | 4891.82 | 781 | 761 | 188.5 |
| D | 7 | 238 | 618794 | 3278.24 | 781 | 761 | 188.5 |
| D | 12 | 233 | 91567 | 481.66 | 781 | 761 | 188.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
