| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_127T01_9000003468_23436cztM0_level2.evt | modeM0/AS1A07_127T01_9000003468_23436cztM0_level2_quad_clean.evt |
| Size (bytes) | 531,993,600 | 73,457,280 |
| Size | 507.3 MB | 70.1 MB |
| Events in quadrant A | 3,532,449 | 448,478 |
| Events in quadrant B | 3,647,804 | 452,107 |
| Events in quadrant C | 4,533,812 | 434,857 |
| Events in quadrant D | 3,948,112 | 426,831 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14253 | 2 |
| B | 0 | 14664 | 2 |
| C | 0 | 17454 | 4 |
| D | 0 | 15685 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6628 | 90 | 1.357876% |
| B | 6628 | 115 | 1.735063% |
| C | 6627 | 409 | 6.171722% |
| D | 6627 | 149 | 2.248378% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7843 | 6628 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7843 | 6628 | 14 | 14 | 0.18% | 0.21% |  |
| C | 7842 | 6628 | 167 | 167 | 2.13% | 2.52% |  |
| D | 7842 | 6627 | 47 | 47 | 0.60% | 0.71% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 10769 | 53.92 | 916 | 898 | 183.1 |
| A | 0 | 226 | 8116 | 39.43 | 916 | 898 | 183.1 |
| A | 3 | 137 | 7493 | 36.03 | 916 | 898 | 183.1 |
| B | 0 | 189 | 53021 | 308.55 | 896 | 875 | 169.0 |
| B | 0 | 228 | 39880 | 230.8 | 896 | 875 | 169.0 |
| B | 0 | 190 | 31930 | 183.76 | 896 | 875 | 169.0 |
| C | 10 | 9 | 999882 | 4956.73 | 869 | 876 | 201.5 |
| C | 14 | 238 | 139356 | 687.09 | 869 | 876 | 201.5 |
| C | 7 | 247 | 6300 | 26.91 | 869 | 876 | 201.5 |
| D | 1 | 52 | 272885 | 1253.62 | 891 | 868 | 217.0 |
| D | 12 | 233 | 122926 | 562.52 | 891 | 868 | 217.0 |
| D | 9 | 85 | 71041 | 323.4 | 891 | 868 | 217.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
