| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_147T01_9000003490_23626cztM0_level2.evt | modeM0/AS1A07_147T01_9000003490_23626cztM0_level2_quad_clean.evt |
| Size (bytes) | 317,237,760 | 40,872,960 |
| Size | 302.5 MB | 39.0 MB |
| Events in quadrant A | 1,396,092 | 280,610 |
| Events in quadrant B | 1,444,395 | 287,786 |
| Events in quadrant C | 1,491,036 | 275,355 |
| Events in quadrant D | 5,084,797 | 193,483 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 5 | 0 |
| C | 0 | 5 | 0 |
| D | 0 | 5 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 58 | 0 |
| B | 0 | 58 | 0 |
| C | 0 | 58 | 0 |
| D | 0 | 58 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5887 | 1 |
| B | 0 | 5950 | 1 |
| C | 0 | 6092 | 1 |
| D | 0 | 17032 | 8 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2791 | 100 | 3.582945% |
| B | 2791 | 109 | 3.905410% |
| C | 2791 | 124 | 4.442852% |
| D | 2790 | 1667 | 59.749104% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 3311 | 2791 | 0 | 0 | 0.00% | 0.00% |  |
| B | 3311 | 2791 | 1 | 1 | 0.03% | 0.04% |  |
| C | 3311 | 2791 | 6 | 6 | 0.18% | 0.21% |  |
| D | 3309 | 2789 | 1502 | 1502 | 45.39% | 53.85% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 96 | 4654 | 57.31 | 361 | 352 | 75.1 |
| A | 13 | 254 | 3958 | 48.04 | 361 | 352 | 75.1 |
| A | 3 | 137 | 3435 | 41.07 | 361 | 352 | 75.1 |
| B | 3 | 64 | 18752 | 253.91 | 359 | 348 | 72.5 |
| B | 12 | 111 | 9029 | 119.77 | 359 | 348 | 72.5 |
| B | 11 | 111 | 7904 | 104.25 | 359 | 348 | 72.5 |
| C | 14 | 238 | 53782 | 640.61 | 345 | 346 | 83.4 |
| C | 8 | 208 | 39248 | 466.37 | 345 | 346 | 83.4 |
| C | 0 | 10 | 33415 | 396.44 | 345 | 346 | 83.4 |
| D | 1 | 52 | 4002089 | 59193.67 | 270 | 261 | 67.6 |
| D | 12 | 233 | 33486 | 491.45 | 270 | 261 | 67.6 |
| D | 8 | 195 | 15930 | 231.77 | 270 | 261 | 67.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
