| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_160T07_9000003494_23663cztM0_level2.evt | modeM0/AS1A07_160T07_9000003494_23663cztM0_level2_quad_clean.evt |
| Size (bytes) | 513,054,720 | 83,044,800 |
| Size | 489.3 MB | 79.2 MB |
| Events in quadrant A | 3,190,575 | 518,112 |
| Events in quadrant B | 3,642,016 | 526,819 |
| Events in quadrant C | 3,294,625 | 512,065 |
| Events in quadrant D | 4,961,564 | 496,537 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13850 | 2 |
| B | 0 | 15263 | 2 |
| C | 0 | 14110 | 2 |
| D | 0 | 19404 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6608 | 57 | 0.862591% |
| B | 6608 | 151 | 2.285109% |
| C | 6608 | 117 | 1.770581% |
| D | 6608 | 621 | 9.397700% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8443 | 6608 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8443 | 6608 | 37 | 37 | 0.44% | 0.56% |  |
| C | 8443 | 6608 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8443 | 6608 | 428 | 428 | 5.07% | 6.48% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 11464 | 63.89 | 826 | 807 | 166.8 |
| A | 3 | 137 | 7337 | 39.15 | 826 | 807 | 166.8 |
| A | 0 | 226 | 7116 | 37.82 | 826 | 807 | 166.8 |
| B | 3 | 64 | 194974 | 1226.76 | 824 | 802 | 158.3 |
| B | 0 | 229 | 89857 | 562.64 | 824 | 802 | 158.3 |
| B | 0 | 228 | 50974 | 316.98 | 824 | 802 | 158.3 |
| C | 14 | 238 | 125133 | 660.11 | 801 | 807 | 188.3 |
| C | 7 | 247 | 46771 | 244.05 | 801 | 807 | 188.3 |
| C | 13 | 61 | 5429 | 24.54 | 801 | 807 | 188.3 |
| D | 1 | 52 | 1100697 | 5726.24 | 785 | 759 | 192.1 |
| D | 9 | 85 | 348415 | 1809.88 | 785 | 759 | 192.1 |
| D | 12 | 233 | 307842 | 1598.66 | 785 | 759 | 192.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
