| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C05_012T03_9000003500_23680cztM0_level2.evt | modeM0/AS1C05_012T03_9000003500_23680cztM0_level2_quad_clean.evt |
| Size (bytes) | 316,229,760 | 91,362,240 |
| Size | 301.6 MB | 87.1 MB |
| Events in quadrant A | 2,238,718 | 613,518 |
| Events in quadrant B | 2,317,566 | 637,408 |
| Events in quadrant C | 2,312,472 | 604,516 |
| Events in quadrant D | 2,389,257 | 582,984 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 96 | 0 |
| B | 0 | 96 | 0 |
| C | 0 | 96 | 0 |
| D | 0 | 96 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9709 | 1 |
| B | 0 | 9891 | 1 |
| C | 0 | 9898 | 1 |
| D | 0 | 10254 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4676 | 28 | 0.598802% |
| B | 4676 | 39 | 0.834046% |
| C | 4676 | 60 | 1.283148% |
| D | 4676 | 29 | 0.620188% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6016 | 4677 | 0 | 0 | 0.00% | 0.00% |  |
| B | 6016 | 4677 | 0 | 0 | 0.00% | 0.00% |  |
| C | 6016 | 4676 | 0 | 0 | 0.00% | 0.00% |  |
| D | 6016 | 4676 | 5 | 5 | 0.08% | 0.11% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 7765 | 61.94 | 581 | 569 | 116.2 |
| A | 0 | 226 | 4966 | 37.85 | 581 | 569 | 116.2 |
| A | 3 | 137 | 4861 | 36.94 | 581 | 569 | 116.2 |
| B | 12 | 111 | 12668 | 111.53 | 583 | 570 | 108.5 |
| B | 11 | 111 | 11179 | 97.81 | 583 | 570 | 108.5 |
| B | 0 | 219 | 10209 | 88.86 | 583 | 570 | 108.5 |
| C | 14 | 238 | 92122 | 713.66 | 559 | 565 | 128.3 |
| C | 7 | 247 | 19869 | 150.47 | 559 | 565 | 128.3 |
| C | 8 | 208 | 13798 | 103.15 | 559 | 565 | 128.3 |
| D | 7 | 238 | 128890 | 950.77 | 558 | 542 | 135.0 |
| D | 1 | 52 | 81506 | 599.76 | 558 | 542 | 135.0 |
| D | 8 | 195 | 37704 | 275.29 | 558 | 542 | 135.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
