| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_027T05_9000003506_23715cztM0_level2.evt | modeM0/AS1A07_027T05_9000003506_23715cztM0_level2_quad_clean.evt |
| Size (bytes) | 208,840,320 | 22,069,440 |
| Size | 199.2 MB | 21.0 MB |
| Events in quadrant A | 1,273,720 | 125,902 |
| Events in quadrant B | 1,455,127 | 129,145 |
| Events in quadrant C | 1,334,362 | 126,353 |
| Events in quadrant D | 2,090,281 | 107,377 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5230 | 2 |
| B | 0 | 5716 | 2 |
| C | 0 | 5364 | 2 |
| D | 0 | 7797 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 52 | 0 |
| B | 0 | 52 | 0 |
| C | 0 | 52 | 0 |
| D | 0 | 52 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2488 | 98 | 3.938907% |
| B | 2487 | 180 | 7.237636% |
| C | 2487 | 145 | 5.830318% |
| D | 2487 | 338 | 13.590671% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 2813 | 2489 | 0 | 0 | 0.00% | 0.00% |  |
| B | 2812 | 2487 | 25 | 25 | 0.89% | 1.01% |  |
| C | 2812 | 2487 | 2 | 2 | 0.07% | 0.08% |  |
| D | 2812 | 2488 | 229 | 229 | 8.14% | 9.20% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 3864 | 51.7 | 330 | 321 | 68.5 |
| A | 3 | 137 | 3217 | 42.26 | 330 | 321 | 68.5 |
| A | 0 | 226 | 2807 | 36.28 | 330 | 321 | 68.5 |
| B | 10 | 247 | 131309 | 2031.16 | 324 | 315 | 64.5 |
| B | 0 | 229 | 28035 | 429.82 | 324 | 315 | 64.5 |
| B | 0 | 189 | 14304 | 216.91 | 324 | 315 | 64.5 |
| C | 14 | 238 | 49544 | 645.87 | 318 | 319 | 76.2 |
| C | 7 | 247 | 44930 | 585.33 | 318 | 319 | 76.2 |
| C | 13 | 61 | 2131 | 23.77 | 318 | 319 | 76.2 |
| D | 1 | 52 | 829953 | 10706.54 | 312 | 301 | 77.5 |
| D | 9 | 35 | 56125 | 720.39 | 312 | 301 | 77.5 |
| D | 9 | 85 | 11049 | 138.7 | 312 | 301 | 77.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
