| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_027T08_9000003514_23734cztM0_level2.evt | modeM0/AS1A07_027T08_9000003514_23734cztM0_level2_quad_clean.evt |
| Size (bytes) | 259,833,600 | 39,168,000 |
| Size | 247.8 MB | 37.4 MB |
| Events in quadrant A | 1,618,598 | 245,099 |
| Events in quadrant B | 1,858,087 | 251,991 |
| Events in quadrant C | 1,645,985 | 235,911 |
| Events in quadrant D | 2,525,174 | 222,680 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 68 | 0 |
| B | 0 | 68 | 0 |
| C | 0 | 68 | 0 |
| D | 0 | 68 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6816 | 1 |
| B | 0 | 7517 | 1 |
| C | 0 | 6800 | 1 |
| D | 0 | 9798 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 3231 | 30 | 0.928505% |
| B | 3231 | 35 | 1.083256% |
| C | 3231 | 55 | 1.702259% |
| D | 3231 | 96 | 2.971216% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 4341 | 3231 | 0 | 0 | 0.00% | 0.00% |  |
| B | 4341 | 3231 | 2 | 2 | 0.05% | 0.06% |  |
| C | 4341 | 3232 | 2 | 2 | 0.05% | 0.06% |  |
| D | 4341 | 3231 | 54 | 54 | 1.24% | 1.67% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 5768 | 62.78 | 418 | 408 | 85.4 |
| A | 0 | 226 | 3680 | 38.33 | 418 | 408 | 85.4 |
| A | 3 | 137 | 3444 | 35.56 | 418 | 408 | 85.4 |
| B | 0 | 229 | 115362 | 1431.74 | 418 | 407 | 80.3 |
| B | 3 | 64 | 60423 | 747.48 | 418 | 407 | 80.3 |
| B | 0 | 189 | 25134 | 307.96 | 418 | 407 | 80.3 |
| C | 14 | 238 | 63738 | 676.64 | 399 | 400 | 93.6 |
| C | 7 | 247 | 17738 | 185.22 | 399 | 400 | 93.6 |
| C | 0 | 10 | 4823 | 47.25 | 399 | 400 | 93.6 |
| D | 8 | 195 | 405184 | 4069.81 | 400 | 388 | 99.5 |
| D | 7 | 238 | 272849 | 2739.31 | 400 | 388 | 99.5 |
| D | 1 | 52 | 250981 | 2519.45 | 400 | 388 | 99.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
