| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A08_009T01_9000003516_23754cztM0_level2.evt | modeM0/AS1A08_009T01_9000003516_23754cztM0_level2_quad_clean.evt |
| Size (bytes) | 476,815,680 | 120,925,440 |
| Size | 454.7 MB | 115.3 MB |
| Events in quadrant A | 3,327,649 | 796,132 |
| Events in quadrant B | 3,532,239 | 832,507 |
| Events in quadrant C | 3,497,975 | 805,862 |
| Events in quadrant D | 3,633,948 | 767,503 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26 | 0 |
| B | 0 | 26 | 0 |
| C | 0 | 26 | 0 |
| D | 0 | 26 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14174 | 2 |
| B | 0 | 14711 | 2 |
| C | 0 | 14599 | 2 |
| D | 0 | 15072 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6598 | 95 | 1.439830% |
| B | 6599 | 140 | 2.121534% |
| C | 6599 | 167 | 2.530686% |
| D | 6599 | 101 | 1.530535% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9253 | 6599 | 0 | 0 | 0.00% | 0.00% |  |
| B | 9254 | 6599 | 6 | 6 | 0.06% | 0.09% |  |
| C | 9254 | 6599 | 0 | 0 | 0.00% | 0.00% |  |
| D | 9254 | 6600 | 9 | 9 | 0.10% | 0.14% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 11816 | 64.21 | 863 | 846 | 170.8 |
| A | 3 | 137 | 7361 | 38.13 | 863 | 846 | 170.8 |
| A | 0 | 226 | 7292 | 37.73 | 863 | 846 | 170.8 |
| B | 0 | 245 | 32404 | 194.28 | 874 | 853 | 162.4 |
| B | 12 | 111 | 18849 | 110.81 | 874 | 853 | 162.4 |
| B | 7 | 219 | 17949 | 105.27 | 874 | 853 | 162.4 |
| C | 14 | 238 | 135575 | 693.04 | 853 | 860 | 194.4 |
| C | 7 | 247 | 30271 | 151.3 | 853 | 860 | 194.4 |
| C | 13 | 61 | 6094 | 26.93 | 853 | 860 | 194.4 |
| D | 8 | 195 | 359234 | 1764.41 | 849 | 824 | 203.1 |
| D | 2 | 234 | 26367 | 125.75 | 849 | 824 | 203.1 |
| D | 9 | 85 | 23630 | 112.27 | 849 | 824 | 203.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
