| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C05_007T01_9000003518_23763cztM0_level2.evt | modeM0/AS1C05_007T01_9000003518_23763cztM0_level2_quad_clean.evt |
| Size (bytes) | 218,157,120 | 18,584,640 |
| Size | 208.1 MB | 17.7 MB |
| Events in quadrant A | 1,335,845 | 93,114 |
| Events in quadrant B | 1,802,051 | 94,485 |
| Events in quadrant C | 1,347,161 | 91,435 |
| Events in quadrant D | 1,936,421 | 89,699 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6 | 0 |
| B | 0 | 7 | 0 |
| C | 0 | 7 | 0 |
| D | 0 | 7 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 54 | 0 |
| B | 0 | 54 | 0 |
| C | 0 | 54 | 0 |
| D | 0 | 54 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5663 | 1 |
| B | 0 | 7107 | 1 |
| C | 0 | 5689 | 1 |
| D | 0 | 7605 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2700 | 8 | 0.296296% |
| B | 2700 | 210 | 7.777778% |
| C | 2700 | 25 | 0.925926% |
| D | 2700 | 33 | 1.222222% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 2700 | 2700 | 0 | 0 | 0.00% | 0.00% |  |
| B | 2700 | 2700 | 138 | 138 | 5.11% | 5.11% |  |
| C | 2700 | 2700 | 0 | 0 | 0.00% | 0.00% |  |
| D | 2700 | 2700 | 25 | 25 | 0.93% | 0.93% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 4810 | 63.73 | 346 | 339 | 70.2 |
| A | 0 | 226 | 3088 | 39.18 | 346 | 339 | 70.2 |
| A | 3 | 137 | 3080 | 39.07 | 346 | 339 | 70.2 |
| B | 3 | 64 | 489484 | 7554.66 | 330 | 322 | 64.7 |
| B | 12 | 111 | 7439 | 109.91 | 330 | 322 | 64.7 |
| B | 11 | 111 | 6824 | 100.41 | 330 | 322 | 64.7 |
| C | 14 | 238 | 53405 | 682.31 | 330 | 333 | 77.8 |
| C | 13 | 61 | 2309 | 25.4 | 330 | 333 | 77.8 |
| C | 0 | 10 | 1772 | 18.5 | 330 | 333 | 77.8 |
| D | 8 | 195 | 343584 | 4094.26 | 336 | 326 | 83.8 |
| D | 1 | 52 | 179199 | 2133.53 | 336 | 326 | 83.8 |
| D | 13 | 174 | 84287 | 1001.46 | 336 | 326 | 83.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
