| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_113T01_9000003526_23793cztM0_level2.evt | modeM0/AS1A07_113T01_9000003526_23793cztM0_level2_quad_clean.evt |
| Size (bytes) | 551,131,200 | 69,592,320 |
| Size | 525.6 MB | 66.4 MB |
| Events in quadrant A | 3,335,335 | 416,813 |
| Events in quadrant B | 3,448,440 | 424,917 |
| Events in quadrant C | 3,374,253 | 412,338 |
| Events in quadrant D | 6,086,605 | 393,686 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14062 | 2 |
| B | 0 | 14375 | 1 |
| C | 0 | 14081 | 1 |
| D | 0 | 22676 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6594 | 58 | 0.879588% |
| B | 6595 | 92 | 1.394996% |
| C | 6595 | 104 | 1.576952% |
| D | 6595 | 437 | 6.626232% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7679 | 6594 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7680 | 6595 | 20 | 20 | 0.26% | 0.30% |  |
| C | 7680 | 6595 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7679 | 6594 | 306 | 306 | 3.98% | 4.64% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 10625 | 56.39 | 865 | 846 | 173.4 |
| A | 3 | 137 | 7427 | 37.95 | 865 | 846 | 173.4 |
| A | 0 | 226 | 7375 | 37.65 | 865 | 846 | 173.4 |
| B | 4 | 216 | 48272 | 291.57 | 855 | 835 | 162.7 |
| B | 12 | 111 | 19111 | 112.33 | 855 | 835 | 162.7 |
| B | 11 | 111 | 17058 | 99.71 | 855 | 835 | 162.7 |
| C | 14 | 238 | 133960 | 692.09 | 828 | 833 | 192.4 |
| C | 7 | 247 | 8066 | 37.6 | 828 | 833 | 192.4 |
| C | 13 | 61 | 5753 | 25.58 | 828 | 833 | 192.4 |
| D | 8 | 195 | 2220642 | 11114.09 | 829 | 806 | 199.7 |
| D | 13 | 174 | 587603 | 2937.93 | 829 | 806 | 199.7 |
| D | 1 | 52 | 92165 | 457.41 | 829 | 806 | 199.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
