| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_149T01_9000003534_23854cztM0_level2.evt | modeM0/AS1A07_149T01_9000003534_23854cztM0_level2_quad_clean.evt |
| Size (bytes) | 437,973,120 | 105,517,440 |
| Size | 417.7 MB | 100.6 MB |
| Events in quadrant A | 2,981,164 | 717,461 |
| Events in quadrant B | 3,140,927 | 729,935 |
| Events in quadrant C | 3,252,458 | 674,900 |
| Events in quadrant D | 3,490,840 | 663,402 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12462 | 1 |
| B | 0 | 12978 | 1 |
| C | 0 | 13316 | 1 |
| D | 0 | 14118 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 120 | 0 |
| B | 0 | 120 | 0 |
| C | 0 | 120 | 0 |
| D | 0 | 120 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5866 | 42 | 0.715990% |
| B | 5867 | 58 | 0.988580% |
| C | 5867 | 85 | 1.448781% |
| D | 5867 | 57 | 0.971536% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7231 | 5867 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7232 | 5868 | 3 | 3 | 0.04% | 0.05% |  |
| C | 7232 | 5868 | 11 | 11 | 0.15% | 0.19% |  |
| D | 7232 | 5868 | 31 | 31 | 0.43% | 0.53% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 10491 | 63.17 | 772 | 760 | 154.1 |
| A | 0 | 226 | 6826 | 39.38 | 772 | 760 | 154.1 |
| A | 3 | 137 | 6173 | 35.14 | 772 | 760 | 154.1 |
| B | 15 | 32 | 111017 | 773.36 | 767 | 752 | 142.6 |
| B | 12 | 111 | 16080 | 107.51 | 767 | 752 | 142.6 |
| B | 11 | 111 | 13867 | 91.98 | 767 | 752 | 142.6 |
| C | 0 | 10 | 187749 | 1133.13 | 719 | 723 | 165.1 |
| C | 7 | 247 | 137735 | 830.11 | 719 | 723 | 165.1 |
| C | 14 | 238 | 119236 | 718.03 | 719 | 723 | 165.1 |
| D | 1 | 52 | 396354 | 2246.58 | 729 | 708 | 176.1 |
| D | 8 | 195 | 160264 | 906.0 | 729 | 708 | 176.1 |
| D | 12 | 233 | 85747 | 482.87 | 729 | 708 | 176.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
