| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_149T01_9000003534_23856cztM0_level2.evt | modeM0/AS1A07_149T01_9000003534_23856cztM0_level2_quad_clean.evt |
| Size (bytes) | 446,685,120 | 108,420,480 |
| Size | 426.0 MB | 103.4 MB |
| Events in quadrant A | 3,053,622 | 725,529 |
| Events in quadrant B | 3,205,096 | 738,691 |
| Events in quadrant C | 3,416,004 | 695,073 |
| Events in quadrant D | 3,420,982 | 680,553 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13172 | 2 |
| B | 0 | 13544 | 2 |
| C | 0 | 14157 | 2 |
| D | 0 | 14554 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6364 | 13 | 0.204274% |
| B | 6364 | 62 | 0.974230% |
| C | 6364 | 86 | 1.351351% |
| D | 6364 | 57 | 0.895663% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7564 | 6365 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7564 | 6365 | 19 | 19 | 0.25% | 0.30% |  |
| C | 7564 | 6365 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7564 | 6365 | 34 | 34 | 0.45% | 0.53% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 11080 | 65.03 | 791 | 777 | 158.4 |
| A | 3 | 137 | 6885 | 38.55 | 791 | 777 | 158.4 |
| A | 0 | 226 | 6752 | 37.71 | 791 | 777 | 158.4 |
| B | 15 | 32 | 58256 | 391.06 | 792 | 774 | 147.0 |
| B | 0 | 189 | 19809 | 129.5 | 792 | 774 | 147.0 |
| B | 12 | 111 | 17221 | 111.89 | 792 | 774 | 147.0 |
| C | 7 | 247 | 329647 | 1886.16 | 751 | 753 | 174.4 |
| C | 14 | 238 | 122932 | 700.68 | 751 | 753 | 174.4 |
| C | 0 | 10 | 22061 | 122.2 | 751 | 753 | 174.4 |
| D | 1 | 52 | 328579 | 1800.31 | 756 | 734 | 182.1 |
| D | 8 | 195 | 153268 | 837.61 | 756 | 734 | 182.1 |
| D | 12 | 218 | 43866 | 236.85 | 756 | 734 | 182.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
