| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_149T01_9000003534_23864cztM0_level2.evt | modeM0/AS1A07_149T01_9000003534_23864cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,488,072,960 | 376,107,840 |
| Size | 1.4 GB | 358.7 MB |
| Events in quadrant A | 10,655,102 | 2,490,104 |
| Events in quadrant B | 10,854,886 | 2,525,955 |
| Events in quadrant C | 10,712,501 | 2,416,774 |
| Events in quadrant D | 11,297,484 | 2,386,479 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 46909 | 4 |
| B | 0 | 47156 | 4 |
| C | 0 | 46897 | 4 |
| D | 0 | 48600 | 4 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 464 | 0 |
| B | 0 | 464 | 0 |
| C | 0 | 464 | 0 |
| D | 0 | 464 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 31 | 0 |
| B | 0 | 31 | 0 |
| C | 0 | 31 | 0 |
| D | 0 | 31 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 22868 | 250 | 1.093231% |
| B | 22869 | 258 | 1.128165% |
| C | 22869 | 366 | 1.600420% |
| D | 22869 | 263 | 1.150028% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 25908 | 22872 | 0 | 0 | 0.00% | 0.00% |  |
| B | 25909 | 22873 | 2 | 2 | 0.01% | 0.01% |  |
| C | 25909 | 22873 | 0 | 0 | 0.00% | 0.00% |  |
| D | 25909 | 22873 | 27 | 27 | 0.10% | 0.12% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 39720 | 67.26 | 2751 | 2693 | 550.5 |
| A | 13 | 252 | 36818 | 61.99 | 2751 | 2693 | 550.5 |
| A | 3 | 137 | 24263 | 39.18 | 2751 | 2693 | 550.5 |
| B | 0 | 189 | 91509 | 173.44 | 2728 | 2659 | 512.3 |
| B | 12 | 111 | 62880 | 117.55 | 2728 | 2659 | 512.3 |
| B | 11 | 111 | 55636 | 103.41 | 2728 | 2659 | 512.3 |
| C | 14 | 238 | 417148 | 679.94 | 2623 | 2633 | 609.6 |
| C | 7 | 247 | 51102 | 79.51 | 2623 | 2633 | 609.6 |
| C | 13 | 61 | 18507 | 26.04 | 2623 | 2633 | 609.6 |
| D | 8 | 195 | 675422 | 1033.63 | 2678 | 2597 | 650.9 |
| D | 1 | 52 | 287667 | 437.94 | 2678 | 2597 | 650.9 |
| D | 12 | 233 | 121309 | 182.37 | 2678 | 2597 | 650.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
