| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_165T01_9000003558_24031cztM0_level2.evt | modeM0/AS1A07_165T01_9000003558_24031cztM0_level2_quad_clean.evt |
| Size (bytes) | 507,660,480 | 136,912,320 |
| Size | 484.1 MB | 130.6 MB |
| Events in quadrant A | 3,294,468 | 937,101 |
| Events in quadrant B | 4,268,362 | 935,448 |
| Events in quadrant C | 3,726,897 | 900,579 |
| Events in quadrant D | 3,613,463 | 890,131 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14297 | 2 |
| B | 0 | 17234 | 2 |
| C | 0 | 15472 | 3 |
| D | 0 | 15386 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6945 | 40 | 0.575954% |
| B | 6945 | 304 | 4.377250% |
| C | 6944 | 83 | 1.195276% |
| D | 6944 | 28 | 0.403226% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7680 | 6946 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7680 | 6946 | 116 | 116 | 1.51% | 1.67% |  |
| C | 7679 | 6945 | 15 | 15 | 0.20% | 0.22% |  |
| D | 7679 | 6945 | 7 | 7 | 0.09% | 0.10% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 1 | 19188 | 109.07 | 849 | 831 | 168.3 |
| A | 13 | 254 | 11804 | 65.2 | 849 | 831 | 168.3 |
| A | 0 | 226 | 7325 | 38.58 | 849 | 831 | 168.3 |
| B | 0 | 197 | 681887 | 4383.78 | 833 | 813 | 155.4 |
| B | 0 | 189 | 285819 | 1834.46 | 833 | 813 | 155.4 |
| B | 12 | 111 | 18042 | 110.9 | 833 | 813 | 155.4 |
| C | 7 | 247 | 334326 | 1799.95 | 806 | 811 | 185.3 |
| C | 14 | 238 | 129746 | 695.85 | 806 | 811 | 185.3 |
| C | 0 | 239 | 108129 | 579.18 | 806 | 811 | 185.3 |
| D | 8 | 195 | 323197 | 1638.66 | 821 | 798 | 196.7 |
| D | 1 | 52 | 137038 | 692.47 | 821 | 798 | 196.7 |
| D | 2 | 234 | 33209 | 164.74 | 821 | 798 | 196.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
