| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_165T01_9000003558_24041cztM0_level2.evt | modeM0/AS1A07_165T01_9000003558_24041cztM0_level2_quad_clean.evt |
| Size (bytes) | 455,693,760 | 133,899,840 |
| Size | 434.6 MB | 127.7 MB |
| Events in quadrant A | 3,079,978 | 925,819 |
| Events in quadrant B | 3,129,742 | 942,040 |
| Events in quadrant C | 3,260,033 | 903,382 |
| Events in quadrant D | 3,927,702 | 869,514 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12793 | 1 |
| B | 0 | 12915 | 1 |
| C | 0 | 13424 | 1 |
| D | 0 | 15410 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 120 | 0 |
| B | 0 | 120 | 0 |
| C | 0 | 120 | 0 |
| D | 0 | 120 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5941 | 26 | 0.437637% |
| B | 5941 | 30 | 0.504965% |
| C | 5942 | 68 | 1.144396% |
| D | 5942 | 223 | 3.752945% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7221 | 5942 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7221 | 5942 | 5 | 5 | 0.07% | 0.08% |  |
| C | 7222 | 5943 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7222 | 5943 | 173 | 173 | 2.40% | 2.91% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 10247 | 60.53 | 796 | 783 | 156.4 |
| A | 0 | 226 | 6949 | 39.43 | 796 | 783 | 156.4 |
| A | 3 | 137 | 6309 | 35.34 | 796 | 783 | 156.4 |
| B | 0 | 190 | 23012 | 153.79 | 787 | 770 | 144.6 |
| B | 5 | 172 | 16548 | 109.09 | 787 | 770 | 144.6 |
| B | 12 | 111 | 16068 | 105.77 | 787 | 770 | 144.6 |
| C | 7 | 247 | 127496 | 722.0 | 766 | 772 | 175.5 |
| C | 14 | 238 | 124166 | 703.03 | 766 | 772 | 175.5 |
| C | 0 | 239 | 18773 | 102.56 | 766 | 772 | 175.5 |
| D | 12 | 218 | 684904 | 3734.54 | 771 | 750 | 183.2 |
| D | 8 | 195 | 147122 | 798.99 | 771 | 750 | 183.2 |
| D | 13 | 104 | 90700 | 491.0 | 771 | 750 | 183.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
