| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_165T01_9000003558_24044cztM0_level2.evt | modeM0/AS1A07_165T01_9000003558_24044cztM0_level2_quad_clean.evt |
| Size (bytes) | 555,670,080 | 137,318,400 |
| Size | 529.9 MB | 131.0 MB |
| Events in quadrant A | 3,250,073 | 951,111 |
| Events in quadrant B | 3,527,757 | 962,831 |
| Events in quadrant C | 3,399,265 | 918,335 |
| Events in quadrant D | 6,213,576 | 875,837 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13500 | 1 |
| B | 0 | 14534 | 1 |
| C | 0 | 13840 | 1 |
| D | 0 | 23082 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6469 | 88 | 1.360334% |
| B | 6470 | 100 | 1.545595% |
| C | 6470 | 128 | 1.978362% |
| D | 6469 | 363 | 5.611377% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7614 | 6470 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7615 | 6471 | 6 | 6 | 0.08% | 0.09% |  |
| C | 7615 | 6471 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7614 | 6470 | 255 | 255 | 3.35% | 3.94% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 1 | 33200 | 197.18 | 832 | 817 | 164.2 |
| A | 13 | 254 | 10732 | 60.37 | 832 | 817 | 164.2 |
| A | 0 | 226 | 7459 | 40.44 | 832 | 817 | 164.2 |
| B | 0 | 197 | 189817 | 1246.45 | 822 | 805 | 151.6 |
| B | 0 | 190 | 35712 | 230.2 | 822 | 805 | 151.6 |
| B | 0 | 189 | 27802 | 178.03 | 822 | 805 | 151.6 |
| C | 7 | 247 | 151624 | 842.94 | 787 | 794 | 178.9 |
| C | 14 | 238 | 128434 | 713.34 | 787 | 794 | 178.9 |
| C | 10 | 9 | 43228 | 237.15 | 787 | 794 | 178.9 |
| D | 8 | 195 | 1559013 | 8216.37 | 793 | 772 | 189.7 |
| D | 1 | 52 | 1305041 | 6877.22 | 793 | 772 | 189.7 |
| D | 12 | 218 | 274339 | 1442.48 | 793 | 772 | 189.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
