| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_165T01_9000003558_24059cztM0_level2.evt | modeM0/AS1A07_165T01_9000003558_24059cztM0_level2_quad_clean.evt |
| Size (bytes) | 448,462,080 | 130,438,080 |
| Size | 427.7 MB | 124.4 MB |
| Events in quadrant A | 3,102,200 | 892,458 |
| Events in quadrant B | 3,340,934 | 898,296 |
| Events in quadrant C | 3,567,415 | 859,498 |
| Events in quadrant D | 3,139,778 | 857,637 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13139 | 1 |
| B | 0 | 13718 | 1 |
| C | 0 | 14717 | 1 |
| D | 0 | 13363 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6342 | 108 | 1.702933% |
| B | 6342 | 130 | 2.049827% |
| C | 6343 | 157 | 2.475169% |
| D | 6343 | 89 | 1.403122% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7327 | 6342 | 3 | 3 | 0.04% | 0.05% |  |
| B | 7327 | 6342 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7328 | 6343 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7328 | 6343 | 9 | 9 | 0.12% | 0.14% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 1 | 34455 | 215.44 | 792 | 778 | 156.3 |
| A | 2 | 250 | 13956 | 84.3 | 792 | 778 | 156.3 |
| A | 13 | 254 | 9469 | 55.6 | 792 | 778 | 156.3 |
| B | 0 | 189 | 152544 | 1050.41 | 783 | 765 | 144.5 |
| B | 0 | 245 | 63096 | 431.37 | 783 | 765 | 144.5 |
| B | 0 | 190 | 23586 | 157.94 | 783 | 765 | 144.5 |
| C | 7 | 247 | 513577 | 2983.83 | 751 | 754 | 171.9 |
| C | 14 | 238 | 122010 | 705.52 | 751 | 754 | 171.9 |
| C | 13 | 61 | 5225 | 26.01 | 751 | 754 | 171.9 |
| D | 1 | 52 | 81692 | 436.48 | 772 | 749 | 185.4 |
| D | 8 | 195 | 50353 | 267.49 | 772 | 749 | 185.4 |
| D | 2 | 234 | 30685 | 161.43 | 772 | 749 | 185.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
