| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_165T01_9000003558_24072cztM0_level2.evt | modeM0/AS1A07_165T01_9000003558_24072cztM0_level2_quad_clean.evt |
| Size (bytes) | 518,837,760 | 145,157,760 |
| Size | 494.8 MB | 138.4 MB |
| Events in quadrant A | 3,336,251 | 1,009,235 |
| Events in quadrant B | 3,465,299 | 1,020,833 |
| Events in quadrant C | 3,567,220 | 969,729 |
| Events in quadrant D | 4,909,564 | 949,558 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13689 | 1 |
| B | 0 | 14070 | 1 |
| C | 0 | 14498 | 1 |
| D | 0 | 19274 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6412 | 67 | 1.044916% |
| B | 6413 | 77 | 1.200686% |
| C | 6413 | 187 | 2.915952% |
| D | 6413 | 167 | 2.604085% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7692 | 6413 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7693 | 6414 | 3 | 3 | 0.04% | 0.05% |  |
| C | 7692 | 6412 | 70 | 70 | 0.91% | 1.09% |  |
| D | 7693 | 6414 | 130 | 130 | 1.69% | 2.03% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 1 | 11149 | 61.02 | 863 | 850 | 168.8 |
| A | 13 | 254 | 10058 | 54.56 | 863 | 850 | 168.8 |
| A | 0 | 226 | 7701 | 40.59 | 863 | 850 | 168.8 |
| B | 0 | 189 | 57419 | 369.01 | 849 | 833 | 153.3 |
| B | 5 | 172 | 36569 | 233.04 | 849 | 833 | 153.3 |
| B | 0 | 228 | 22482 | 141.18 | 849 | 833 | 153.3 |
| C | 10 | 9 | 217498 | 1164.45 | 818 | 825 | 186.1 |
| C | 14 | 238 | 133735 | 714.29 | 818 | 825 | 186.1 |
| C | 7 | 247 | 18798 | 96.59 | 818 | 825 | 186.1 |
| D | 8 | 195 | 1181319 | 5840.0 | 840 | 816 | 202.1 |
| D | 1 | 52 | 467306 | 2307.75 | 840 | 816 | 202.1 |
| D | 11 | 176 | 45281 | 219.97 | 840 | 816 | 202.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
