| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_165T01_9000003558_24080cztM0_level2.evt | modeM0/AS1A07_165T01_9000003558_24080cztM0_level2_quad_clean.evt |
| Size (bytes) | 203,624,640 | 49,150,080 |
| Size | 194.2 MB | 46.9 MB |
| Events in quadrant A | 1,258,755 | 332,192 |
| Events in quadrant B | 1,317,245 | 337,838 |
| Events in quadrant C | 1,295,952 | 325,072 |
| Events in quadrant D | 2,119,066 | 309,522 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 5 | 0 |
| C | 0 | 5 | 0 |
| D | 0 | 5 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5275 | 1 |
| B | 0 | 5429 | 1 |
| C | 0 | 5392 | 1 |
| D | 0 | 8007 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 54 | 0 |
| B | 0 | 54 | 0 |
| C | 0 | 54 | 0 |
| D | 0 | 54 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2553 | 29 | 1.135919% |
| B | 2554 | 40 | 1.566171% |
| C | 2554 | 50 | 1.957713% |
| D | 2554 | 199 | 7.791699% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 3098 | 2554 | 0 | 0 | 0.00% | 0.00% |  |
| B | 3099 | 2555 | 0 | 0 | 0.00% | 0.00% |  |
| C | 3099 | 2555 | 5 | 5 | 0.16% | 0.20% |  |
| D | 3099 | 2554 | 150 | 150 | 4.84% | 5.87% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 4522 | 63.0 | 325 | 317 | 66.7 |
| A | 3 | 137 | 3031 | 40.66 | 325 | 317 | 66.7 |
| A | 2 | 250 | 2863 | 38.15 | 325 | 317 | 66.7 |
| B | 0 | 197 | 32249 | 501.67 | 323 | 315 | 63.7 |
| B | 0 | 229 | 9211 | 139.75 | 323 | 315 | 63.7 |
| B | 12 | 111 | 7263 | 109.15 | 323 | 315 | 63.7 |
| C | 14 | 238 | 47480 | 639.49 | 305 | 307 | 73.8 |
| C | 0 | 239 | 27017 | 362.09 | 305 | 307 | 73.8 |
| C | 7 | 247 | 24384 | 326.39 | 305 | 307 | 73.8 |
| D | 1 | 52 | 667486 | 8808.78 | 305 | 295 | 75.7 |
| D | 8 | 195 | 279813 | 3690.42 | 305 | 295 | 75.7 |
| D | 2 | 234 | 13243 | 170.95 | 305 | 295 | 75.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
