| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_182T01_9000003560_24083cztM0_level2.evt | modeM0/AS1T03_182T01_9000003560_24083cztM0_level2_quad_clean.evt |
| Size (bytes) | 498,551,040 | 104,287,680 |
| Size | 475.5 MB | 99.5 MB |
| Events in quadrant A | 3,421,181 | 675,532 |
| Events in quadrant B | 3,486,577 | 693,667 |
| Events in quadrant C | 3,517,039 | 669,479 |
| Events in quadrant D | 4,209,987 | 643,542 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14329 | 2 |
| B | 0 | 14533 | 2 |
| C | 0 | 14551 | 2 |
| D | 0 | 16873 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6829 | 59 | 0.863963% |
| B | 6829 | 62 | 0.907893% |
| C | 6829 | 103 | 1.508274% |
| D | 6829 | 133 | 1.947577% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7979 | 6829 | 2 | 2 | 0.03% | 0.03% |  |
| B | 7979 | 6829 | 1 | 1 | 0.01% | 0.01% |  |
| C | 7979 | 6829 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7979 | 6829 | 74 | 74 | 0.93% | 1.08% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 16 | 17729 | 95.34 | 880 | 862 | 176.9 |
| A | 13 | 254 | 11708 | 61.31 | 880 | 862 | 176.9 |
| A | 2 | 250 | 8830 | 45.04 | 880 | 862 | 176.9 |
| B | 12 | 111 | 19500 | 111.98 | 882 | 862 | 166.4 |
| B | 11 | 111 | 16824 | 95.9 | 882 | 862 | 166.4 |
| B | 14 | 111 | 15002 | 84.95 | 882 | 862 | 166.4 |
| C | 14 | 238 | 135751 | 674.55 | 858 | 867 | 200.0 |
| C | 7 | 247 | 23579 | 113.58 | 858 | 867 | 200.0 |
| C | 3 | 233 | 7282 | 32.08 | 858 | 867 | 200.0 |
| D | 8 | 195 | 418896 | 1963.6 | 864 | 839 | 212.9 |
| D | 11 | 176 | 301509 | 1412.24 | 864 | 839 | 212.9 |
| D | 1 | 52 | 106997 | 498.62 | 864 | 839 | 212.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
