| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C05_012T04_9000003564_24101cztM0_level2.evt | modeM0/AS1C05_012T04_9000003564_24101cztM0_level2_quad_clean.evt |
| Size (bytes) | 128,960,640 | 35,588,160 |
| Size | 123.0 MB | 33.9 MB |
| Events in quadrant A | 852,006 | 246,002 |
| Events in quadrant B | 842,936 | 248,929 |
| Events in quadrant C | 834,544 | 236,681 |
| Events in quadrant D | 1,268,160 | 231,173 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 32 | 0 |
| B | 0 | 32 | 0 |
| C | 0 | 32 | 0 |
| D | 0 | 32 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3417 | 1 |
| B | 0 | 3395 | 1 |
| C | 0 | 3375 | 1 |
| D | 0 | 4942 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 1555 | 71 | 4.565916% |
| B | 1555 | 91 | 5.852090% |
| C | 1554 | 84 | 5.405405% |
| D | 1554 | 73 | 4.697555% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 2825 | 1555 | 0 | 0 | 0.00% | 0.00% |  |
| B | 2825 | 1555 | 0 | 0 | 0.00% | 0.00% |  |
| C | 2824 | 1554 | 0 | 0 | 0.00% | 0.00% |  |
| D | 2824 | 1554 | 10 | 10 | 0.35% | 0.64% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 2440 | 48.74 | 221 | 217 | 45.6 |
| A | 0 | 226 | 1907 | 37.05 | 221 | 217 | 45.6 |
| A | 3 | 137 | 1904 | 36.99 | 221 | 217 | 45.6 |
| B | 12 | 111 | 4895 | 113.15 | 215 | 211 | 41.4 |
| B | 11 | 111 | 4286 | 98.43 | 215 | 211 | 41.4 |
| B | 14 | 111 | 3861 | 88.17 | 215 | 211 | 41.4 |
| C | 14 | 238 | 33883 | 720.37 | 203 | 204 | 46.8 |
| C | 0 | 10 | 3109 | 62.14 | 203 | 204 | 46.8 |
| C | 10 | 9 | 2373 | 46.39 | 203 | 204 | 46.8 |
| D | 8 | 195 | 327907 | 6310.16 | 211 | 204 | 51.9 |
| D | 11 | 176 | 84604 | 1625.18 | 211 | 204 | 51.9 |
| D | 1 | 52 | 19097 | 363.8 | 211 | 204 | 51.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
