| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_069T01_9000003570_24126cztM0_level2.evt | modeM0/AS1A07_069T01_9000003570_24126cztM0_level2_quad_clean.evt |
| Size (bytes) | 450,126,720 | 81,573,120 |
| Size | 429.3 MB | 77.8 MB |
| Events in quadrant A | 3,133,742 | 517,624 |
| Events in quadrant B | 3,217,711 | 528,067 |
| Events in quadrant C | 3,156,680 | 495,861 |
| Events in quadrant D | 3,688,613 | 481,495 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13230 | 2 |
| B | 0 | 13426 | 2 |
| C | 0 | 13251 | 2 |
| D | 0 | 15200 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6409 | 16 | 0.249649% |
| B | 6409 | 21 | 0.327664% |
| C | 6409 | 48 | 0.748947% |
| D | 6409 | 47 | 0.733344% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7544 | 6410 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7544 | 6410 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7544 | 6410 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7544 | 6410 | 31 | 31 | 0.41% | 0.48% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 10085 | 56.88 | 812 | 797 | 163.3 |
| A | 3 | 137 | 7090 | 38.54 | 812 | 797 | 163.3 |
| A | 0 | 226 | 6838 | 36.99 | 812 | 797 | 163.3 |
| B | 12 | 111 | 18899 | 117.53 | 812 | 794 | 154.0 |
| B | 4 | 171 | 16801 | 103.91 | 812 | 794 | 154.0 |
| B | 11 | 111 | 16648 | 102.92 | 812 | 794 | 154.0 |
| C | 14 | 238 | 121941 | 666.4 | 774 | 781 | 181.8 |
| C | 3 | 233 | 7396 | 36.38 | 774 | 781 | 181.8 |
| C | 2 | 16 | 5582 | 26.41 | 774 | 781 | 181.8 |
| D | 8 | 195 | 386186 | 2033.23 | 780 | 758 | 189.6 |
| D | 1 | 52 | 253921 | 1335.5 | 780 | 758 | 189.6 |
| D | 7 | 238 | 35358 | 182.52 | 780 | 758 | 189.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
