| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_160T05_9000003580_24201cztM0_level2.evt | modeM0/AS1A07_160T05_9000003580_24201cztM0_level2_quad_clean.evt |
| Size (bytes) | 469,540,800 | 93,098,880 |
| Size | 447.8 MB | 88.8 MB |
| Events in quadrant A | 3,341,451 | 611,492 |
| Events in quadrant B | 3,396,200 | 623,346 |
| Events in quadrant C | 3,600,020 | 574,422 |
| Events in quadrant D | 3,443,619 | 559,356 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13702 | 2 |
| B | 0 | 13918 | 2 |
| C | 0 | 14731 | 2 |
| D | 0 | 14152 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6460 | 16 | 0.247678% |
| B | 6460 | 29 | 0.448916% |
| C | 6460 | 53 | 0.820433% |
| D | 6459 | 20 | 0.309645% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7835 | 6461 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7835 | 6461 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7835 | 6461 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7834 | 6460 | 5 | 5 | 0.06% | 0.08% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 10569 | 56.49 | 867 | 851 | 172.0 |
| A | 0 | 226 | 7675 | 39.67 | 867 | 851 | 172.0 |
| A | 3 | 137 | 6852 | 34.88 | 867 | 851 | 172.0 |
| B | 12 | 111 | 18466 | 110.92 | 866 | 848 | 158.8 |
| B | 11 | 111 | 16607 | 99.22 | 866 | 848 | 158.8 |
| B | 14 | 111 | 14945 | 88.75 | 866 | 848 | 158.8 |
| C | 7 | 247 | 264721 | 1408.45 | 817 | 825 | 187.4 |
| C | 14 | 238 | 133769 | 709.54 | 817 | 825 | 187.4 |
| C | 2 | 16 | 11230 | 55.53 | 817 | 825 | 187.4 |
| D | 8 | 195 | 281610 | 1404.6 | 823 | 799 | 199.9 |
| D | 12 | 233 | 43365 | 212.91 | 823 | 799 | 199.9 |
| D | 2 | 234 | 25267 | 122.39 | 823 | 799 | 199.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
