| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_118T01_9000003586_24264cztM0_level2.evt | modeM0/AS1A07_118T01_9000003586_24264cztM0_level2_quad_clean.evt |
| Size (bytes) | 969,667,200 | 162,740,160 |
| Size | 924.7 MB | 155.2 MB |
| Events in quadrant A | 6,181,363 | 1,026,233 |
| Events in quadrant B | 6,319,019 | 1,053,570 |
| Events in quadrant C | 6,617,109 | 1,003,462 |
| Events in quadrant D | 9,380,479 | 957,793 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26542 | 1 |
| B | 0 | 26779 | 1 |
| C | 0 | 27554 | 1 |
| D | 0 | 36350 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 260 | 0 |
| B | 0 | 260 | 0 |
| C | 0 | 260 | 0 |
| D | 0 | 260 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 12827 | 406 | 3.165198% |
| B | 12828 | 430 | 3.352042% |
| C | 12828 | 509 | 3.967883% |
| D | 12828 | 970 | 7.561584% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 13242 | 12827 | 0 | 0 | 0.00% | 0.00% |  |
| B | 13243 | 12828 | 3 | 3 | 0.02% | 0.02% |  |
| C | 13243 | 12829 | 45 | 45 | 0.34% | 0.35% |  |
| D | 13243 | 12828 | 559 | 559 | 4.22% | 4.36% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 20233 | 57.59 | 1600 | 1561 | 324.2 |
| A | 3 | 1 | 14541 | 40.03 | 1600 | 1561 | 324.2 |
| A | 3 | 137 | 14527 | 39.99 | 1600 | 1561 | 324.2 |
| B | 12 | 111 | 37079 | 116.77 | 1590 | 1545 | 304.3 |
| B | 11 | 111 | 33108 | 103.72 | 1590 | 1545 | 304.3 |
| B | 14 | 111 | 28162 | 87.47 | 1590 | 1545 | 304.3 |
| C | 2 | 16 | 358346 | 989.25 | 1537 | 1547 | 360.7 |
| C | 14 | 238 | 239627 | 660.09 | 1537 | 1547 | 360.7 |
| C | 7 | 247 | 30782 | 81.06 | 1537 | 1547 | 360.7 |
| D | 12 | 233 | 1402743 | 3709.72 | 1541 | 1495 | 377.7 |
| D | 8 | 195 | 1246057 | 3294.91 | 1541 | 1495 | 377.7 |
| D | 1 | 52 | 513762 | 1356.2 | 1541 | 1495 | 377.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
