| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C05_007T01_9000003588_24274cztM0_level2.evt | modeM0/AS1C05_007T01_9000003588_24274cztM0_level2_quad_clean.evt |
| Size (bytes) | 594,783,360 | 102,530,880 |
| Size | 567.2 MB | 97.8 MB |
| Events in quadrant A | 3,538,436 | 681,306 |
| Events in quadrant B | 3,437,349 | 701,930 |
| Events in quadrant C | 3,926,054 | 668,157 |
| Events in quadrant D | 6,679,201 | 608,068 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14050 | 2 |
| B | 0 | 13836 | 2 |
| C | 0 | 16042 | 2 |
| D | 0 | 24608 | 7 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 19 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6378 | 74 | 1.160238% |
| B | 6378 | 61 | 0.956413% |
| C | 6378 | 83 | 1.301348% |
| D | 6377 | 755 | 11.839423% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7748 | 6379 | 19 | 19 | 0.25% | 0.30% |  |
| B | 7748 | 6378 | 2 | 2 | 0.03% | 0.03% |  |
| C | 7748 | 6379 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7747 | 6378 | 783 | 783 | 10.11% | 12.28% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 16 | 144451 | 821.31 | 882 | 868 | 174.8 |
| A | 13 | 254 | 9323 | 48.36 | 882 | 868 | 174.8 |
| A | 0 | 226 | 7709 | 39.13 | 882 | 868 | 174.8 |
| B | 12 | 111 | 18940 | 110.83 | 875 | 857 | 163.2 |
| B | 11 | 111 | 17048 | 99.23 | 875 | 857 | 163.2 |
| B | 14 | 111 | 15158 | 87.65 | 875 | 857 | 163.2 |
| C | 7 | 247 | 364943 | 1844.11 | 853 | 860 | 197.4 |
| C | 14 | 238 | 137130 | 690.22 | 853 | 860 | 197.4 |
| C | 2 | 16 | 97842 | 491.22 | 853 | 860 | 197.4 |
| D | 1 | 52 | 2711075 | 13376.34 | 840 | 820 | 202.6 |
| D | 8 | 195 | 684683 | 3375.18 | 840 | 820 | 202.6 |
| D | 12 | 233 | 104303 | 510.74 | 840 | 820 | 202.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
