| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_145T01_9000003594_24349cztM0_level2.evt | modeM0/AS1A07_145T01_9000003594_24349cztM0_level2_quad_clean.evt |
| Size (bytes) | 717,333,120 | 84,435,840 |
| Size | 684.1 MB | 80.5 MB |
| Events in quadrant A | 2,983,560 | 559,075 |
| Events in quadrant B | 3,057,144 | 577,588 |
| Events in quadrant C | 6,514,810 | 527,505 |
| Events in quadrant D | 8,746,696 | 455,444 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13559 | 645 |
| B | 0 | 13691 | 667 |
| C | 0 | 24790 | 1046 |
| D | 0 | 32908 | 2654 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 6 |
| B | 0 | 136 | 10 |
| C | 0 | 135 | 7 |
| D | 0 | 135 | 5 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6292 | 11 | 0.174825% |
| B | 6284 | 38 | 0.604710% |
| C | 6256 | 421 | 6.729540% |
| D | 6172 | 2001 | 32.420609% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7432 | 6369 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7397 | 6356 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7414 | 6341 | 35 | 35 | 0.47% | 0.55% |  |
| D | 7281 | 6271 | 1761 | 1761 | 24.19% | 28.08% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 8790 | 51.87 | 772 | 756 | 154.9 |
| A | 3 | 137 | 6878 | 39.52 | 772 | 756 | 154.9 |
| A | 0 | 226 | 6693 | 38.33 | 772 | 756 | 154.9 |
| B | 12 | 111 | 18236 | 116.59 | 775 | 756 | 149.9 |
| B | 11 | 111 | 15922 | 101.16 | 775 | 756 | 149.9 |
| B | 14 | 111 | 14434 | 91.23 | 775 | 756 | 149.9 |
| C | 7 | 247 | 3523002 | 20720.51 | 728 | 732 | 170.0 |
| C | 14 | 238 | 113203 | 661.63 | 728 | 732 | 170.0 |
| C | 2 | 16 | 25605 | 146.32 | 728 | 732 | 170.0 |
| D | 12 | 218 | 2781912 | 18237.34 | 628 | 608 | 152.5 |
| D | 7 | 238 | 1785617 | 11704.52 | 628 | 608 | 152.5 |
| D | 1 | 52 | 840605 | 5507.96 | 628 | 608 | 152.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
