| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_054T01_9000003604_24419cztM0_level2.evt | modeM0/AS1A07_054T01_9000003604_24419cztM0_level2_quad_clean.evt |
| Size (bytes) | 458,369,280 | 132,007,680 |
| Size | 437.1 MB | 125.9 MB |
| Events in quadrant A | 2,941,860 | 898,342 |
| Events in quadrant B | 3,134,179 | 931,921 |
| Events in quadrant C | 3,261,243 | 901,260 |
| Events in quadrant D | 4,130,030 | 840,716 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12749 | 2 |
| B | 0 | 13238 | 2 |
| C | 0 | 13525 | 2 |
| D | 0 | 16330 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6103 | 10 | 0.163854% |
| B | 6103 | 28 | 0.458791% |
| C | 6103 | 55 | 0.901196% |
| D | 6103 | 157 | 2.572505% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7463 | 6104 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7463 | 6104 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7463 | 6104 | 2 | 2 | 0.03% | 0.03% |  |
| D | 7463 | 6104 | 108 | 108 | 1.45% | 1.77% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 10418 | 64.05 | 763 | 748 | 151.0 |
| A | 0 | 226 | 6397 | 37.42 | 763 | 748 | 151.0 |
| A | 3 | 137 | 6348 | 37.09 | 763 | 748 | 151.0 |
| B | 0 | 190 | 36850 | 254.99 | 776 | 757 | 141.5 |
| B | 3 | 64 | 34191 | 236.21 | 776 | 757 | 141.5 |
| B | 15 | 32 | 22125 | 150.96 | 776 | 757 | 141.5 |
| C | 14 | 238 | 122905 | 702.1 | 759 | 766 | 174.0 |
| C | 7 | 247 | 82121 | 467.66 | 759 | 766 | 174.0 |
| C | 3 | 233 | 38073 | 214.45 | 759 | 766 | 174.0 |
| D | 9 | 35 | 612874 | 3433.51 | 739 | 720 | 178.3 |
| D | 1 | 52 | 324629 | 1816.77 | 739 | 720 | 178.3 |
| D | 12 | 218 | 187995 | 1050.41 | 739 | 720 | 178.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
