| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_183T01_9000003606_24448cztM0_level2.evt | modeM0/AS1T03_183T01_9000003606_24448cztM0_level2_quad_clean.evt |
| Size (bytes) | 463,896,000 | 115,548,480 |
| Size | 442.4 MB | 110.2 MB |
| Events in quadrant A | 3,063,306 | 784,864 |
| Events in quadrant B | 3,178,285 | 811,686 |
| Events in quadrant C | 3,289,969 | 752,497 |
| Events in quadrant D | 4,100,350 | 721,754 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13017 | 2 |
| B | 0 | 13311 | 2 |
| C | 0 | 13709 | 2 |
| D | 0 | 16462 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 19 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6146 | 40 | 0.650830% |
| B | 6146 | 47 | 0.764725% |
| C | 6146 | 78 | 1.269118% |
| D | 6146 | 310 | 5.043931% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7466 | 6147 | 4 | 4 | 0.05% | 0.07% |  |
| B | 7466 | 6147 | 6 | 6 | 0.08% | 0.10% |  |
| C | 7466 | 6147 | 4 | 4 | 0.05% | 0.07% |  |
| D | 7466 | 6147 | 258 | 258 | 3.46% | 4.20% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 2 | 39977 | 251.59 | 785 | 771 | 155.8 |
| A | 13 | 254 | 10058 | 59.6 | 785 | 771 | 155.8 |
| A | 3 | 137 | 6880 | 39.2 | 785 | 771 | 155.8 |
| B | 3 | 64 | 60126 | 405.52 | 791 | 773 | 146.4 |
| B | 12 | 111 | 17291 | 112.86 | 791 | 773 | 146.4 |
| B | 7 | 202 | 17047 | 111.19 | 791 | 773 | 146.4 |
| C | 2 | 16 | 217234 | 1237.49 | 752 | 756 | 174.9 |
| C | 14 | 238 | 121370 | 689.49 | 752 | 756 | 174.9 |
| C | 3 | 233 | 20427 | 112.45 | 752 | 756 | 174.9 |
| D | 1 | 52 | 880491 | 5048.04 | 725 | 706 | 174.3 |
| D | 12 | 218 | 298705 | 1709.86 | 725 | 706 | 174.3 |
| D | 13 | 174 | 111006 | 632.88 | 725 | 706 | 174.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
