| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_183T01_9000003606_24511cztM0_level2.evt | modeM0/AS1T03_183T01_9000003606_24511cztM0_level2_quad_clean.evt |
| Size (bytes) | 613,105,920 | 134,858,880 |
| Size | 584.7 MB | 128.6 MB |
| Events in quadrant A | 4,487,723 | 909,472 |
| Events in quadrant B | 4,357,665 | 916,351 |
| Events in quadrant C | 3,845,138 | 875,718 |
| Events in quadrant D | 5,345,739 | 837,419 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18547 | 2 |
| B | 0 | 18129 | 2 |
| C | 0 | 16620 | 2 |
| D | 0 | 21196 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 160 | 0 |
| B | 0 | 160 | 0 |
| C | 0 | 160 | 0 |
| D | 0 | 160 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 6 | 0 |
| D | 0 | 6 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7852 | 232 | 2.954661% |
| B | 7852 | 442 | 5.629139% |
| C | 7851 | 289 | 3.681060% |
| D | 7851 | 466 | 5.935550% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8287 | 7855 | 3 | 3 | 0.04% | 0.04% |  |
| B | 8287 | 7855 | 74 | 74 | 0.89% | 0.94% |  |
| C | 8286 | 7854 | 21 | 21 | 0.25% | 0.27% |  |
| D | 8286 | 7854 | 216 | 216 | 2.61% | 2.75% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 111 | 866605 | 4570.64 | 938 | 916 | 189.4 |
| A | 13 | 254 | 12433 | 60.81 | 938 | 916 | 189.4 |
| A | 3 | 137 | 8567 | 40.4 | 938 | 916 | 189.4 |
| B | 3 | 64 | 680229 | 3766.67 | 929 | 902 | 180.4 |
| B | 12 | 111 | 22241 | 118.32 | 929 | 902 | 180.4 |
| B | 11 | 111 | 19467 | 102.94 | 929 | 902 | 180.4 |
| C | 14 | 238 | 143884 | 681.61 | 901 | 906 | 209.8 |
| C | 2 | 16 | 102807 | 485.78 | 901 | 906 | 209.8 |
| C | 10 | 9 | 83744 | 394.91 | 901 | 906 | 209.8 |
| D | 1 | 52 | 887766 | 4118.32 | 895 | 867 | 215.4 |
| D | 12 | 218 | 411016 | 1904.53 | 895 | 867 | 215.4 |
| D | 8 | 195 | 396923 | 1839.09 | 895 | 867 | 215.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
