| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_189T01_9000003614_24610cztM0_level2.evt | modeM0/AS1T03_189T01_9000003614_24610cztM0_level2_quad_clean.evt |
| Size (bytes) | 531,043,200 | 101,004,480 |
| Size | 506.4 MB | 96.3 MB |
| Events in quadrant A | 3,374,603 | 660,433 |
| Events in quadrant B | 4,685,234 | 648,235 |
| Events in quadrant C | 4,020,358 | 638,094 |
| Events in quadrant D | 3,536,220 | 633,203 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14442 | 2 |
| B | 0 | 18385 | 2 |
| C | 0 | 16254 | 3 |
| D | 0 | 15018 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6878 | 45 | 0.654260% |
| B | 6878 | 387 | 5.626636% |
| C | 6877 | 139 | 2.021230% |
| D | 6877 | 26 | 0.378072% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7568 | 6879 | 3 | 3 | 0.04% | 0.04% |  |
| B | 7568 | 6879 | 208 | 208 | 2.75% | 3.02% |  |
| C | 7567 | 6878 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7567 | 6878 | 1 | 1 | 0.01% | 0.01% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 96 | 43452 | 246.66 | 862 | 846 | 172.7 |
| A | 13 | 254 | 10660 | 56.82 | 862 | 846 | 172.7 |
| A | 6 | 16 | 9002 | 47.22 | 862 | 846 | 172.7 |
| B | 3 | 64 | 1347252 | 8357.72 | 842 | 818 | 161.1 |
| B | 0 | 245 | 22132 | 132.3 | 842 | 818 | 161.1 |
| B | 12 | 111 | 20148 | 119.99 | 842 | 818 | 161.1 |
| C | 7 | 247 | 604167 | 3109.09 | 834 | 841 | 194.1 |
| C | 14 | 238 | 133115 | 681.64 | 834 | 841 | 194.1 |
| C | 3 | 233 | 22042 | 109.25 | 834 | 841 | 194.1 |
| D | 8 | 195 | 230708 | 1118.26 | 847 | 822 | 205.6 |
| D | 1 | 52 | 95039 | 458.31 | 847 | 822 | 205.6 |
| D | 2 | 234 | 29796 | 140.94 | 847 | 822 | 205.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
